DS2778G+T&R
ActiveAnalog Devices Inc./Maxim Integrated
IC BATT MFUNC LI-ION 2CEL 14TDFN
Deep-Dive with AI
Search across all available documentation for this part.
DS2778G+T&R
ActiveAnalog Devices Inc./Maxim Integrated
IC BATT MFUNC LI-ION 2CEL 14TDFN
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS2778G+T&R | DS2778 Series |
|---|---|---|
| Battery Chemistry | Lithium Ion/Polymer | Lithium Ion/Polymer |
| Fault Protection | Over Current, Over Voltage | Over Current, Over Voltage |
| Function | Multi-Function Controller | Multi-Function Controller |
| Interface | I2C | I2C |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Cells | 2 | 2 |
| Operating Temperature [Max] | 70 °C | 70 °C |
| Operating Temperature [Min] | -20 °C | -20 °C |
| Package / Case | 14-WFDFN Exposed Pad | 14-WFDFN Exposed Pad |
| Supplier Device Package | 14-TDFN (3x5) | 14-TDFN (3x5) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 2500 | $ 4.63 | |
DS2778 Series
IC BATT MFUNC LI-ION 2CEL 14TDFN
| Part | Battery Chemistry | Number of Cells | Package / Case | Function | Mounting Type | Interface | Operating Temperature [Max] | Operating Temperature [Min] | Fault Protection | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DS2778G+T&R | Lithium Ion/Polymer | 2 | 14-WFDFN Exposed Pad | Multi-Function Controller | Surface Mount | I2C | 70 °C | -20 °C | Over Current, Over Voltage | 14-TDFN (3x5) |
Analog Devices Inc./Maxim Integrated DS2778G+ | Lithium Ion/Polymer | 2 | 14-WFDFN Exposed Pad | Multi-Function Controller | Surface Mount | I2C | 70 °C | -20 °C | Over Current, Over Voltage | 14-TDFN (3x5) |
Description
General part information
DS2778 Series
Battery Multi-Function Controller IC Lithium Ion/Polymer 14-TDFN (3x5)
