General part information
Position Terminal Block
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
3D models and CAD resources for this part
Technical documentation and resources
| Part | Termination Style | Wire Gauge or Range - AWG (Max) | Wire Gauge or Range - AWG (Min) | Number of Levels | Features | Wire Gauge or Range - mm² (Maximum) | Wire Gauge or Range - mm² (Minimum) | Operating Temperature (Min) | Operating Temperature (Max) | Color | Contact Mating Finish | Current - UL | Positions Per Level | Voltage - UL | Plug Wire Entry Angle | Type | Number of Positions | Pitch | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | |||||||||||||||||||
 Molex | Push-In Spring Screwless - Leg Spring | 24 AWG | 16 AWG | 1 | Push Button Actuated | 1.5 mm² | 0.25 mm² | -40 °C | 105 °C | Green | Tin | 8 A | 12 | 150 V | 180 ° | Female Sockets Plug | 12 | 0.138 in | Free Hanging (In-Line) |
Molex | |||||||||||||||||||
 Molex | Push-In Spring Screwless - Leg Spring | 24 AWG | 16 AWG | 1 | Push Button Actuated | 1.5 mm² | 0.25 mm² | -40 °C | 105 °C | Green | Tin | 8 A | 2 | 150 V | 180 ° | Female Sockets Plug | 2 | 0.138 in | Free Hanging (In-Line) |
