B4502NS
ActiveTE Connectivity Raychem Cable Protection
RF ANT 460MHZ WHIP STR NMO BASE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
B4502NS
ActiveTE Connectivity Raychem Cable Protection
RF ANT 460MHZ WHIP STR NMO BASE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | B4502NS |
|---|---|
| Antenna Type | Whip, Straight |
| Frequency (Center/Band) | 460 MHz |
| Frequency Group [Max] | 1 GHz |
| Frequency Group [Min] | 300 MHz |
| Frequency Range [Max] | 470 MHz |
| Frequency Range [Min] | 450 MHz |
| Gain | 2.4 dBi |
| Height (Max) | 317.5 mm |
| Height (Max) [Max] [z] | 12.5 in |
| Mounting Type | Base Mount |
| Number of Bands | 1 |
| Termination | NMO |
| VSWR | 2 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 40.05 | |
| 10 | $ 37.37 | |||
| 25 | $ 35.80 | |||
| 100 | $ 32.44 | |||
| 250 | $ 31.33 | |||
Description
General part information
B4502 Series
RF ANTENNA Whip, Straight NMO Base Mount
