R121316000

Active

Radiall USA, Inc.

SSMA / RIGHT ANGLE BULKHEAD JACK

Search across all available documentation for this part.

Active

Radiall USA, Inc.

SSMA / RIGHT ANGLE BULKHEAD JACK

Technical Specifications

Parameters and characteristics for this part

Specification	R121316000

Body Finish	Nickel
Body Material	Stainless Steel
Cable Group	RG-405 (.085" Semi Rigid)
Center Contact Material	Bronze
Center Contact Plating	Gold
Connector Style	SSMA
Connector Type	Female Socket, Jack
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	18 GHz
Housing Color	Silver
Impedance	50 Ohms
Mounting Feature	Bulkhead - Rear Side Nut
Number of Ports	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-65 ░C
Shield Termination	Solder

Part	Housing Color	Operating Temperature [Max]	Operating Temperature [Min]	Body Finish	Center Contact Plating	Frequency - Max [Max]	Mounting Feature	Connector Style	Impedance	Center Contact Material	Connector Type	Number of Ports	Shield Termination	Dielectric Material	Cable Group	Contact Termination	Body Material
Radiall USA, Inc. R121316000	Silver	125 °C	-65 ░C	Nickel	Gold	18 GHz	Bulkhead - Rear Side Nut	SSMA	50 Ohms	Bronze	Female Socket Jack	1	Solder	Polytetrafluoroethylene (PTFE)	RG-405 (.085" Semi Rigid)	Solder	Stainless Steel

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	25	$ 97.43

General part information

SSMA Connector Jack, Female Socket 50 Ohms Panel Mount Solder
