Specification	ENP-360-48

Applications	ITE (Commercial)
Approval Agency	CE, CB, cULus
Current - Output 1	6.5 A
Efficiency	94 %
Features	PFC, Adjustable Output, Universal Input
Minimum Load Required	No
Mounting Type	Benchtop
Number of Outputs	1
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-30 °C
Power (Watts)	359 W
Size / Dimension Height	1.79 in
Size / Dimension Length	7.56 in
Size / Dimension Width	7.01 in
Type	Enclosed
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	90 V
Voltage - Input (DC) Maximum	370 V
Voltage - Input (DC) Minimum	127 VDC
Voltage - Isolation	3 kV
Voltage - Output 1	55.2 V

ENP-360 Series

Part	Minimum Load Required	Voltage - Input (DC) Maximum	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum	Voltage - Input (DC) Minimum	Number of Outputs	Power (Watts)	Mounting Type	Size / Dimension Width	Size / Dimension Length	Size / Dimension Height	Features	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Isolation	Current - Output 1	Applications	Type	Approval Agency	Voltage - Output 1	Efficiency
MEAN WELL USA Inc. ENP-360-48	No	370 V	90 V	264 V	127 VDC	1	359 W	Benchtop	7.01 in	7.56 in	1.79 in	Adjustable Output PFC Universal Input	70 °C	-30 °C	3 kV	6.5 A	ITE (Commercial)	Enclosed	CB CE cULus	55.2 V	94 %
