0452010.NRL
ActiveFUSE, SURFACE MOUNT, 10 A, SLOW BLOW, 72 V, 75 V, 2410 [6125 METRIC], NANO2 SLO-BLO 452 SERIES
0452010.NRL
ActiveFUSE, SURFACE MOUNT, 10 A, SLOW BLOW, 72 V, 75 V, 2410 [6125 METRIC], NANO2 SLO-BLO 452 SERIES
Description
General part information
452010 Series
The NANO2® Slo-Blo® fuse has enhanced inrush withstand characteristics over the NANO2® Fast-Acting fuse. The unique time delay feature of this fuse design helps solve the problem of nuisance "opening" by accommodating inrush currents that normally cause a fast-acting fuse to open.
Technical Specifications
Parameters and characteristics for this part
| Specification | 0452010.NRL |
|---|---|
| Approval Agency | TUV, UKCA, CSA, CE, cURus |
| Breaking Capacity | 50 A |
| Current Rating | 10 A |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 195 |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2-SMD, Square End Block |
| Response Time | Slow Blow |
| Size / Dimension Height | 0.106 in |
| Size / Dimension Length | 0.24 in |
| Size / Dimension Width | 0.106 in |
| Voltage Rating - AC | 72 V |
| Voltage Rating - DC | 60 V |
