SMM02070C1803FBP00

Active

RES THIN FILM 0207(2309) 180K OHM 1% 0.4W ±50PPM/°C SULFUR RESISTANT MELF PAD SMD T/R AUTOMOTIVE AEC-Q200

Active

RES THIN FILM 0207(2309) 180K OHM 1% 0.4W ±50PPM/°C SULFUR RESISTANT MELF PAD SMD T/R AUTOMOTIVE AEC-Q200

Description

General part information

180 kOhms ±1% 1W Chip Resistor MELF, 0207 Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding Thin Film

Parameters and characteristics for this part

Specification	SMM02070C1803FBP00

Composition	Thin Film
Features	Anti-Sulfur, Pulse Withstanding, Automotive AEC-Q200
Number of Terminations	2
Operating Temperature (Max)	155 °C
Operating Temperature (Min)	-55 °C
Package / Case	0207, MELF
Package Name	MELF
Power (Watts)	1 W
Resistance	180 kOhm
Size / Dimension Diameter	0.087 in
Size / Dimension Length	0.228 in
Temperature Coefficient	50 ppm/°C
Tolerance	1 %

Part	Resistance	Package / Case	Features	Composition	Size / Dimension Length	Size / Dimension Diameter	Number of Terminations	Tolerance	Package Name	Operating Temperature (Max)	Operating Temperature (Min)	Power (Watts)	Ratings	Temperature Coefficient
Vishay Dale SMM02070C3902FBS00
Vishay Dale SMM02070C8208FBP00	8.2 Ohm	0207 MELF	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	Thin Film	0.228 in	0.087 in	2	1 %	MELF	155 °C	-55 °C	1 W	AEC-Q200	50 ppm/°C
Vishay Dale SMM02070C1803FBP00	180 kOhm	0207 MELF	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	Thin Film	0.228 in	0.087 in	2	1 %	MELF	155 °C	-55 °C	1 W		50 ppm/°C
Vishay Dale SMM02070C1808FBP00	1.8 Ohm	0207 MELF	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	Thin Film	0.228 in	0.087 in	2	1 %	MELF	155 °C	-55 °C	1 W		50 ppm/°C
Vishay Dale SMM02070C1000FBP00	100 Ohms	0207 MELF	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	Thin Film	0.228 in	0.087 in	2	1 %	MELF	155 °C	-55 °C	1 W		50 ppm/°C
Vishay Dale SMM02070C1803FBP00	180 kOhm	0207 MELF	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	Thin Film	0.228 in	0.087 in	2	1 %	MELF	155 °C	-55 °C	1 W	AEC-Q200	50 ppm/°C
Vishay Dale SMM02070C1870FBP00
Vishay Dale SMM02070C2209FBS00
Vishay Dale SMM02070C1808FBP00	1.8 Ohm	0207 MELF	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	Thin Film	0.228 in	0.087 in	2	1 %	MELF	155 °C	-55 °C	1 W	AEC-Q200	50 ppm/°C
Vishay Dale SMM02070C4703FBP00	470 kOhm	0207 MELF	Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding	Thin Film	0.228 in	0.087 in	2	1 %	MELF	155 °C	-55 °C	1 W		50 ppm/°C
