9965 0091000

Active

Belden Inc.

CBL 1COND STRND 22AWG WHT

Search across all available documentation for this part.

Active

Belden Inc.

CBL 1COND STRND 22AWG WHT

Technical Specifications

Parameters and characteristics for this part

Specification	9965 0091000

Cable Type	Hook-Up, Shielded
Conductor Material	Copper, Tinned
Conductor Strand	34 AWG
Conductor Strand [custom]	19 Strands
Jacket (Insulation) Diameter [diameter]	2.48 mm
Jacket (Insulation) Diameter [diameter]	0.098 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.25 mm
Jacket (Insulation) Thickness	0.01 in
Length	1000 ft
Length	304.8 m
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-20 C
Qualification	MIL-W-16878E/17
Voltage	600 V
Wire Gauge	22 AWG

Part	Conductor Strand [custom]	Conductor Strand	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Qualification	Voltage	Wire Gauge	Length	Length	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type
Belden Inc. 9965 0091000	19 Strands	34 AWG	0.25 mm	0.01 in	Poly-Vinyl Chloride (PVC)	2.48 mm	0.098 in	Copper Tinned	MIL-W-16878E/17	600 V	22 AWG	1000 ft	304.8 m	-20 C	105 ░C	Hook-Up Shielded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 2.57

General part information

22 AWG Hook-Up, Shielded Wire 19/34 White 600V 1000.0' (304.8m)
