8881MN 004100

Active

Belden Inc.

CABLE 15COND 20AWG YLW SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 15COND 20AWG YLW SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	8881MN 004100

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Tinned
Conductor Strand	34 AWG, 26
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.304 in
Jacket (Insulation) Diameter [diameter]	7.72 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.406 mm
Jacket (Insulation) Thickness	0.016 in
Jacket Color	Yellow
Length [x]	30.5 m
Length [x]	100 ft
Number of Conductors	15
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2937
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Usage	Audio, Instrumentation, Control
Voltage	300 V
Wire Gauge	20 AWG

Part	Shield Material	Conductor Insulation	Jacket Color	Conductor Strand	Cable Type	Ratings	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Shield Coverage	Voltage	Shield Type	Conductor Material	Features	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Number of Conductors	Jacket (Insulation) Material	Usage	Length [x]	Length [x]	Length	Length
Belden Inc. 8881MN 004100	Aluminum	Polypropylene (PP)	Yellow	26 34 AWG	Multi-Conductor	UL Style 2937	0.304 in	7.72 mm	0.406 mm	0.016 in	100 %	300 V	Foil	Copper Tinned	Drain Wire	20 AWG	-20 C	80 C	15	Poly-Vinyl Chloride (PVC)	Audio Control Instrumentation	30.5 m	100 ft
Belden Inc. 8881MN 0081000	Aluminum	Polypropylene (PP)	Gray	26 34 AWG	Multi-Conductor	UL Style 2937	0.304 in	7.72 mm	0.406 mm	0.016 in	100 %	300 V	Foil	Copper Tinned	Drain Wire	20 AWG	-20 C	80 C	15	Poly-Vinyl Chloride (PVC)	Audio Control Instrumentation			1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

15 Conductor Multi-Conductor Cable Yellow 20 AWG Foil 100.0' (30.5m)
