858-308

Active

WAGO Corporation

RELAY GEN PURPOSE 4PDT 5A 220V

858-308

Active

WAGO Corporation

RELAY GEN PURPOSE 4PDT 5A 220V

Description Specifications Series Pricing CAD Documents

Description

General part information

- Series

General Purpose Relay 4PDT (4 Form C) 220VDC Coil DIN Rail

Technical Specifications

Parameters and characteristics for this part

Specification	858-308

Coil Current	4.1 mA
Coil Resistance	53.66 kOhms
Coil Type	Non Latching
Coil Voltage	220 V
Contact Form	PDT, 4, Form, C
Contact Material	Silver Cerium (AgCe)
Contact Rating (Current)	5 A
Features	Lighted Indicator
Load - Max Switching (Apparent Power)	1250 VA
Mounting Type	DIN Rail
Operate Time	25 ms
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-25 °C
Pin Count	4
Relay Type	General Purpose
Release Time	25 ms
Switching Voltage AC (Max)	250 VAC
Termination Style	Spring Terminal

- Series

...

Part	Load - Max Switching (Apparent Power)	Coil Voltage	Features	Release Time	Contact Rating (Current)	Switching Voltage AC (Max)	Contact Material	Relay Type	Operating Temperature (Max)	Operating Temperature (Min)	Termination Style	Mounting Type	Coil Type	Operate Time	Pin Count	Contact Form	Coil Current	Coil Resistance	Form A Count	Circuit	Approval Agency	Voltage - Input	Package / Case	Load Current	Output Type	Voltage - Load (Max)	Voltage - Load (Min)	Coil Voltage (Type)	Coil Voltage (Max)	Coil Voltage (Min)
WAGO Corporation 858-308	1250 VA	220 V	Lighted Indicator	25 ms	5 A	250 VAC	Silver Cerium (AgCe)	General Purpose	70 °C	-25 °C	Spring Terminal	DIN Rail	Non Latching	25 ms	4	4 C Form PDT	4.1 mA	53.66 kOhms
WAGO Corporation 788-155	4000 VA	24 VDC		3 ms	16 A	250 VAC	Gold (Au) Silver Nickel (AgNi)	General Purpose	85 °C	-40 °C	PC Pin	Through Hole	Non Latching	7 ms		1 C Form SPDT	17 mA	1.41 kOhms
WAGO Corporation 2042-3004	1500 VA	24 VDC	Lighted Indicator	4 ms	6 A	250 VAC	Silver Tin Oxide (AgSnO)	General Purpose	70 °C	-40 °C	Plug In	Socketable	Non Latching	8 ms		SPST-NO	6.6 mA	3.64 kOhms	1
WAGO Corporation 788-721									70 °C	-20 °C	Spring Terminal	DIN Rail								SPST-NO (1 Form A)	UL	24 V 24 V	Module	4 A	AC Zero Cross	275 V	12 V
WAGO Corporation 857-368	1500 VA	230 VDC		25 ms	6 A	250 VAC	Gold (Au) Silver Nickel (AgNi)	General Purpose	60 °C	-40 °C	Spring Terminal	DIN Rail	Non Latching	15 ms		1 C Form SPDT	3.5 mA	65.71 kOhms			EAC UL							AC DC
WAGO Corporation 2042-3024	1250 VA	24 VDC	Lighted Indicator	6 ms	5 A	250 VAC	Silver Nickel (AgNi)	General Purpose	70 °C	-40 °C	Plug In	Socketable	Non Latching	8 ms	4	4 Form A PST-NO	28.1 mA	854.09 Ohms
WAGO Corporation 788-549	2000 VA	230 VDC	Lighted Indicator	8 ms	8 A	250 VAC	Silver Nickel (AgNi)	General Purpose	70 °C	-40 °C	Spring Terminal	DIN Rail	Non Latching	15 ms		2 2 Form C C DPDT Form	3.2 mA	71.88 kOhms
WAGO Corporation 2042-3889	750 VA		Lighted Indicator	6 ms	3 A	250 VAC	Silver Nickel (AgNi)	General Purpose	50 °C	-40 °C	Plug In	Socketable	Non Latching	8 ms	4	2 A B Form PST-2NO/2NC	6 mA	38.33 kOhms										AC DC	230 VAC/DC	24 VAC
WAGO Corporation 789-552	1000 VA	24 VDC	Lighted Indicator	20 ms	4 A	250 VAC	Gold (Au) Silver Nickel (AgNi)	General Purpose	40 °C	-20 °C	Spring Terminal	DIN Rail	Non Latching	20 ms	4	4 Form A PST-NO	12 mA	2000 Ohms			EAC							AC DC
WAGO Corporation 857-153	1500 VA	24 VDC		4 ms	6 A	250 VAC	Silver Nickel (AgNi)	General Purpose	85 °C	-40 °C	PC Pin	Through Hole	Non Latching	8 ms		1 C Form SPDT					UL

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

858-308 | Datasheet
