CHS1204805-B
ActiveCosel USA, Inc.
DC DC CONVERTER 5V 120W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CHS1204805-B
ActiveCosel USA, Inc.
DC DC CONVERTER 5V 120W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CHS1204805-B |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 24 A |
| Efficiency | 93 % |
| Features | OCP, OVP, Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 8-DIP Module |
| Power (Watts) | 120 W |
| Size / Dimension [x] | 33.5 mm |
| Size / Dimension [x] | 1.32 " |
| Size / Dimension [y] | 23.4 mm |
| Size / Dimension [y] | 0.92 " |
| Size / Dimension [z] | 12.7 mm |
| Size / Dimension [z] | 0.5 in |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 76 V |
| Voltage - Input (Min) [Min] | 36 V |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 80.49 | |
Description
General part information
CHS1204805 Series
Isolated Module DC DC Converter 1 Output 5V 24A 36V - 76V Input
