AEA052N00000203000

Active

TE Intercontec

CONN RCPT HSG MALE 12POS PNL MT

Search across all available documentation for this part.

Active

TE Intercontec

CONN RCPT HSG MALE 12POS PNL MT

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AEA052N00000203000	AEA05 Series

Connector Type	Receptacle Housing	Receptacle Housing
Contact Shape	Circular	Circular
Fastening Type	Push-Twist	Push-Twist
Housing Color	Silver	Silver
Includes	1 O-Ring, 1 Connector, 1 Nut	1 O-Ring, 1 Connector, 1 Nut
Ingress Protection	IP66/IP67	IP66/IP67
Insert Material	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Feature	Bulkhead - Rear Side Nut	Bulkhead - Rear Side Nut, Flange
Note	Contacts Not Included	Contacts Not Included
Number of Positions	12	12
Operating Temperature [Max]	130 °C	130 °C
Operating Temperature [Min]	-20 C	-20 C
Orientation	Keyed	Keyed
Shell Finish	Nickel	Nickel
Shell Material	Zinc Die Cast	Zinc Die Cast
Shell Size - Insert	M23-12	M23-12
Shielding	Unshielded	Unshielded
Type	For Male Pins	For Male Pins

CONN RCPT HSG MALE 12POS PNL MT

Part	Connector Type	Housing Color	Type	Fastening Type	Number of Positions	Material Flammability Rating	Shell Finish	Mounting Feature	Ingress Protection	Shell Material	Shielding	Includes	Operating Temperature [Min]	Operating Temperature [Max]	Orientation	Contact Shape	Insert Material	Shell Size - Insert	Note
TE Intercontec AEA052N00000203000	Receptacle Housing	Silver	For Male Pins	Push-Twist	12	UL94 V-0	Nickel	Bulkhead - Rear Side Nut	IP66/IP67	Zinc Die Cast	Unshielded	1 Connector, 1 Nut, 1 O-Ring	-20 C	130 °C	Keyed	Circular	Polybutylene Terephthalate (PBT)	M23-12	Contacts Not Included
TE Intercontec AEA052N00000201000	Receptacle Housing	Silver	For Male Pins	Push-Twist	12	UL94 V-0	Nickel	Flange	IP66/IP67	Zinc Die Cast	Unshielded	1 Connector, 1 O-Ring	-20 C	130 °C	Keyed	Circular	Polybutylene Terephthalate (PBT)	M23-12	Contacts Not Included

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

12 Position Circular Connector Receptacle Housing Panel Mount
