000-1075

Active

AMPHENOL RF

CONN TERMINATOR SMA

Search across all available documentation for this part.

Active

AMPHENOL RF

CONN TERMINATOR SMA

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	000-1075	000-10 Series

Body Finish	Silver	Nickel, Silver
Body Material	Brass	Brass
Center Contact Material	-	Beryllium Copper
Center Contact Plating	-	Silver
Connector Style	SMA	MHV, SMA
Connector Type	-	Receptacle, Female Socket
Contact Termination	-	Solder Eyelet
Dielectric Material	-	Polytetrafluoroethylene (PTFE)
Fastening Type	-	Bayonet Lock
Features	-	Extended Insulation
Housing Color	-	Silver
Impedance	-	Non-Constant
Includes	-	1 Nut, 1 Connector, 1 Lockwasher
Ingress Protection	-	IP67 - Dust Tight, Waterproof
Mating Cycles	-	500
Mounting Feature	-	Bulkhead - Front Side Nut
Mounting Type	Panel Mount, Bulkhead - Front Side Nut	Panel Mount, Bulkhead - Front Side Nut
Number of Ports	-	1
Operating Temperature	-	-65 ░C
Operating Temperature	-	165 °C
Shield Termination	-	Solder
Voltage Rating	-	5000 V

CONN MHV RCPT STR SOLDER

Part	Mounting Feature	Shield Termination	Operating Temperature [Min]	Operating Temperature [Max]	Includes	Connector Type	Ingress Protection	Fastening Type	Mating Cycles	Voltage Rating	Impedance	Connector Style	Housing Color	Contact Termination	Number of Ports	Dielectric Material	Center Contact Plating	Body Material	Features	Center Contact Material	Body Finish	Mounting Type
AMPHENOL RF 000-10400	Bulkhead - Front Side Nut	Solder	-65 ░C	165 °C	1 Connector, 1 Lockwasher, 1 Nut	Female Socket, Receptacle	IP67 - Dust Tight, Waterproof	Bayonet Lock	500	5000 V	Non-Constant	MHV	Silver	Solder Eyelet	1	Polytetrafluoroethylene (PTFE)	Silver	Brass	Extended Insulation	Beryllium Copper	Nickel
AMPHENOL RF 000-1075												SMA						Brass			Silver	Panel Mount, Bulkhead - Front Side Nut

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Terminator Coax Connector SMA
