CRLB-1-3057 Series

Part	Ratings	Voltage	Lamp Color	Lens Style	Lens Color	Current	Panel Cutout Shape	Wavelength - Peak	Viewing Angle	Termination Length	Termination Style	Millicandela Rating	Ingress Protection	Type	Panel Cutout Dimension	Lens Size	Lens Size (Code)
Visual Communications Company - VCC CRLB-1-3057-9909-I	DC If (Max) Vf (Typ)	3.3 V 12 VDC	Blue	Domed Top Round	Blue	20 mA	Round	468 nm	20 °	6 in	Wire Leads	640 mcd	IP67	LED	0.32 "	5 mm	T-1 3/4
Visual Communications Company - VCC CRLB-1-3057-9911-I	DC If (Max) Vf (Typ)	3.3 V 24 V	Blue	Domed Top Round	Blue	20 mA	Round	468 nm	20 °	6 in	Wire Leads	640 mcd	IP67	LED	0.32 "	5 mm	T-1 3/4
Visual Communications Company - VCC CRLB-1-3057-9913-I	DC If (Max) Vf (Typ)	3.3 V 48 V	Blue	Domed Top Round	Blue	20 mA	Round	468 nm	20 °	6 in	Wire Leads	640 mcd	IP67	LED	0.32 "	5 mm	T-1 3/4
Visual Communications Company - VCC CRLB-1-3057-9923-I	DC If (Max) Vf (Typ)	3.3 V 28 V	Blue	Domed Top Round	Blue	20 mA	Round	468 nm	20 °	6 in	Wire Leads	640 mcd	IP67	LED	0.32 "	5 mm	T-1 3/4
Visual Communications Company - VCC CRLB-1-3057-9933-I	DC If (Max) Vf (Typ)	3.3 V 28 V	Blue	Domed Top Round	Blue	20 mA	Round	468 nm	20 °	6 in	Wire Leads	640 mcd	IP67	LED	0.32 "	5 mm	T-1 3/4
Visual Communications Company - VCC CRLB-1-3057-9922-I	DC If (Max) Vf (Typ)	3.3 V 5 VDC	Blue	Domed Top Round	Blue	20 mA	Round	468 nm	20 °	6 in	Wire Leads	640 mcd	IP67	LED	0.32 "	5 mm	T-1 3/4
Visual Communications Company - VCC CRLB-1-3057-0000-I	If (Max) Vf (Typ)	3.3 V	Blue	Domed Top Round	Blue	20 mA	Round	468 nm	20 °	6 in	Wire Leads	640 mcd	IP67	LED	0.32 "	5 mm	T-1 3/4
