EALP05RDHGA1
ActiveEverlight Electronics Co Ltd
LED YLW-GRN DIFFUSED 5MM T/H
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
EALP05RDHGA1
ActiveEverlight Electronics Co Ltd
LED YLW-GRN DIFFUSED 5MM T/H
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | EALP05RDHGA1 |
|---|---|
| Color | Yellow-Green |
| Configuration | Standard |
| Current - Test | 20 mA |
| Height (Max) [Max] [z] | 8.9 mm |
| Lens Color | Green |
| Lens Size [diameter] | 5 mm Dia |
| Lens Style | Round with Domed Top |
| Lens Transparency | Diffused |
| Millicandela Rating | 200 mcd |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Supplier Device Package | 5 mm |
| Viewing Angle | 25 ° |
| Voltage - Forward (Vf) (Typ) | 2 V |
| Wavelength - Dominant | 573 nm |
| Wavelength - Peak | 575 nm |
EALP05 Series
| Part | Height (Max) [Max] [z] | Lens Style | Package / Case | Lens Transparency | Lens Color | Lens Size [diameter] | Voltage - Forward (Vf) (Typ) | Millicandela Rating | Color | Viewing Angle | Mounting Type | Current - Test | Configuration | Wavelength - Peak | Wavelength - Dominant | Supplier Device Package | Lens Size | Lens Size | Supplier Device Package | Millicandela Rating [custom] | Millicandela Rating [custom] | Supplier Device Package [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Diffused | White | 5 mm Dia | 2 V | 125 mcd | Yellow-Green | 35 ° | Through Hole | 20 mA | Standard | 575 nm | 573 nm | 5 mm | ||||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Clear | Colorless | 3.2 V | 6750 mcd | White | 50 ° | Through Hole | 20 mA | Standard | T-1 3/4 | 5 mm | T-1 3/4 (5mm) | |||||||
Everlight Electronics Co Ltd | 8.85 mm | Round with Domed Top | Radial | Clear | Colorless | 3.3 V | 2000 mcd | Blue | 20 ° | Through Hole | 20 mA | 468 nm | 470 nm | T-1 3/4 | 5 mm | T-1 3/4 (5mm) | ||||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Clear | Colorless | 5 mm Dia | 2 V | 2000 mcd | Red | 6 ° | Through Hole | 20 mA | Standard | 650 nm | 639 nm | 5 mm | ||||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Clear | Colorless | 5 mm Dia | 2 V | 3200 mcd | Yellow | 10 ° | Through Hole | 20 mA | Standard | 591 nm | 589 nm | 5 mm | ||||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Clear | Colorless | 3.2 V | 10700 mcd | White | 20 ° | Through Hole | 20 mA | Standard | T-1 3/4 | 5 mm | T-1 3/4 (5mm) | |||||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Clear | Colorless | 3.2 V | 21375 mcd | White | 15 ° | Through Hole | 20 mA | Standard | T-1 3/4 | 5 mm | T-1 3/4 (5mm) | |||||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Diffused | White | 5 mm Dia | 2 V 2 V | Green Yellow | 80 ° | Through Hole | 20 mA 20 mA | Bidirectional | 575 nm 591 nm | 573 nm 589 nm | 5 mm | 80 mcd | 32 mcd | |||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Clear | Colorless | 2 V | 2500 mcd | Red | 6 ° | Through Hole | 20 mA | 632 nm | 624 nm | T-1 3/4 | 5 mm | 5 mm | ||||||
Everlight Electronics Co Ltd | 8.9 mm | Round with Domed Top | Radial | Diffused | Green | 5 mm Dia | 2 V | 200 mcd | Yellow-Green | 25 ° | Through Hole | 20 mA | Standard | 575 nm | 573 nm | 5 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.46 | |
| 10 | $ 0.30 | |||
| 100 | $ 0.20 | |||
| 500 | $ 0.14 | |||
| 1000 | $ 0.12 | |||
| 2000 | $ 0.10 | |||
| 5000 | $ 0.10 | |||
| 10000 | $ 0.09 | |||
| 25000 | $ 0.08 | |||
Description
General part information
EALP05 Series
Yellow-Green 573nm LED Indication - Discrete 2V Radial
