3079T 0105000

Active

Belden Inc.

CABLE 2COND 22AWG BLK SHLD 5000'

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 22AWG BLK SHLD 5000'

Technical Specifications

Parameters and characteristics for this part

Specification	3079T 0105000

Cable Type	Multi-Conductor
Conductor Insulation	Polyethylene (PE)
Conductor Material	Copper, Bare
Conductor Strand	Solid
Features	UV Resistant, Flame Retardant
Jacket Color	Black
Number of Conductors	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-20 C
Shield Coverage	100 %, 65 %
Shield Material	Copper, Tinned, Aluminum
Shield Type	Foil, Braid
Voltage	300 V
Wire Gauge	22 AWG

Part	Operating Temperature [Min]	Operating Temperature [Max]	Jacket Color	Conductor Material	Wire Gauge	Shield Type	Number of Conductors	Cable Type	Voltage	Shield Material	Conductor Insulation	Features	Conductor Strand	Shield Coverage
Belden Inc. 3079T 0105000	-20 C	105 ░C	Black	Copper Bare	22 AWG	Braid Foil	2	Multi-Conductor	300 V	Aluminum Copper Tinned	Polyethylene (PE)	Flame Retardant UV Resistant	Solid	65 % 100 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

2 (1 Pair) Conductor Multi-Conductor Cable Black 22 AWG Foil, Braid 5000' (1524.0m)
