XZMYH160S
ActiveSunLED
LED YELLOW CLEAR 2SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XZMYH160S
ActiveSunLED
LED YELLOW CLEAR 2SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XZMYH160S |
|---|---|
| Color | Yellow |
| Configuration | Standard |
| Current - Test | 350 mA |
| Height (Max) [Max] [z] | 2.2 mm |
| Lens Color | Colorless |
| Lens Size [diameter] | 2.6 mm |
| Lens Style | Round with Domed Top |
| Lens Transparency | Clear |
| Millicandela Rating | 47.7 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD, No Lead |
| Size / Dimension [x] | 3.45 mm |
| Size / Dimension [y] | 3.45 mm |
| Supplier Device Package | 2-SMD |
| Viewing Angle | 120 ° |
| Voltage - Forward (Vf) (Typ) | 2.5 V |
| Wavelength - Dominant | 593 nm |
| Wavelength - Peak | 594 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.74 | |
| 10 | $ 1.82 | |||
| 100 | $ 1.40 | |||
| 500 | $ 1.27 | |||
| Digi-Reel® | 1 | $ 2.74 | ||
| 10 | $ 1.82 | |||
| 100 | $ 1.40 | |||
| 500 | $ 1.27 | |||
| Tape & Reel (TR) | 1000 | $ 0.97 | ||
Description
General part information
XZMYH160 Series
Yellow 593nm LED Indication - Discrete 2.5V 2-SMD, No Lead
