Specification	ELVH-M250D-HRRJ-C-N4A4

Accuracy	0.25 %
Features	Temperature Compensated
Maximum Pressure	12.33 PSI
Mounting Type	Surface Mount
Operating Pressure (Max)	3.63 PSI
Operating Pressure (Min)	-0.29 PSI
Operating Temperature (Max)	50 °C
Operating Temperature (Min)	0 °C
Output Bits	14 b
Output Type	I2C
Package / Case	Dual Ports, 8-SMD, Same Side, J-Lead
Port Diameter	0.06 in
Port Feature	Tube, Dual
Port Gender	Male
Port Style	Barbed
Pressure Type	Differential
Termination Style	J Lead
Voltage - Supply	3.3 V
Voltage - Supply (Maximum)	5.5 V
Voltage - Supply (Minimum)	2.7 V

ELVH-M250D Series

Part	Voltage - Supply	Operating Pressure (Max)	Operating Pressure (Min)	Mounting Type	Package / Case	Output Type	Features	Pressure Type	Operating Temperature (Max)	Operating Temperature (Min)	Maximum Pressure	Accuracy	Port Diameter	Port Feature	Port Gender	Port Style	Output Bits	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Termination Style	Package Name	Package Width	Package Features	Package Length
McGill Microwave Systems ELVH-M250D-HRRJ-I-N3A5	5 VDC	3.63 PSI	-0.29 PSI	Surface Mount	8-SMD Dual Ports J-Lead Same Side	I2C	Temperature Compensated	Differential	85 °C	-20 °C	12.33 PSI	0.25 %	0.06 in	Dual Tube	Male	Barbed	14 b	5.5 V	2.7 V	J Lead
McGill Microwave Systems ELVH-M250D-HRRD-C-NSA4	3.3 V	3.63 PSI	-0.29 PSI	Through Hole		SPI	Temperature Compensated	Differential	50 °C	0 °C	12.33 PSI	0.25 %	0.06 in	Dual Tube	Male	Barbed	14 b	5.5 V	2.7 V	PC Pin	8-DIP	12.8 mm	Dual Ports Same Side	0.504 in
McGill Microwave Systems ELVH-M250D-HRRJ-C-N4A4	3.3 V	3.63 PSI	-0.29 PSI	Surface Mount	8-SMD Dual Ports J-Lead Same Side	I2C	Temperature Compensated	Differential	50 °C	0 °C	12.33 PSI	0.25 %	0.06 in	Dual Tube	Male	Barbed	14 b	5.5 V	2.7 V	J Lead
McGill Microwave Systems ELVH-M250D-HRRJ-C-NAA4	3.3 V	3.63 PSI	-0.29 PSI	Surface Mount	8-SMD Dual Ports J-Lead Same Side	Analog Voltage	Temperature Compensated	Differential	50 °C	0 °C	12.33 PSI	0.25 %	0.06 in	Dual Tube	Male	Barbed		5.5 V	2.7 V	J Lead
