IL 3585

Active

NVE Corp/Isolation Products

DGT ISO 2.5KV RS422/RS485 16SOIC

Search across all available documentation for this part.

Active

NVE Corp/Isolation Products

DGT ISO 2.5KV RS422/RS485 16SOIC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

RS422, RS485 Digital Isolator 2500Vrms 3 Channel 40Mbps 30kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	IL 3585	IL 3585 Series

Channel Type	Unidirectional	Unidirectional
Common Mode Transient Immunity (Min) [Min]	30 kV/µs	30 kV/µs
Data Rate	40 Mbps	40 Mbps
Inputs - Side 1/Side 2 [custom]	2	2
Inputs - Side 1/Side 2 [custom]	1	1
Isolated Power	False	False
Mounting Type	Surface Mount	Surface Mount
Number of Channels [custom]	3	3
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	16-SOIC	16-SOIC
Package / Case [x]	0.295 in	0.154 - 0.295 in
Package / Case [y]	7.5 mm	3.9 - 7.5 mm
Propagation Delay tpLH / tpHL (Max)	35 ns	35 ns
Supplier Device Package	16-SOIC	16-SOIC
Technology	GMR (Giant Magnetoresistive)	GMR (Giant Magnetoresistive)
Type	RS422, RS485	RS422, RS485
Voltage - Isolation	2500 Vrms	2500 - 6000 Vrms
Voltage - Supply [Max]	5.5 V	5.5 V
Voltage - Supply [Min]	4.5 V, 3 V	3 - 4.5 V

DGT ISO 2.5KV RS422/RS485 16SOIC

Part	Supplier Device Package	Voltage - Isolation	Voltage - Supply [Min]	Voltage - Supply [Max]	Type	Common Mode Transient Immunity (Min) [Min]	Package / Case	Package / Case [x]	Package / Case [y]	Channel Type	Mounting Type	Number of Channels [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Inputs - Side 1/Side 2 [custom]	Inputs - Side 1/Side 2 [custom]	Propagation Delay tpLH / tpHL (Max)	Technology	Data Rate
NVE Corp/Isolation Products IL 3585-3E	16-SOIC	2500 Vrms	3 V, 4.5 V	5.5 V	RS422, RS485	30 kV/µs	16-SOIC	0.154 in	3.9 mm	Unidirectional	Surface Mount	3	85 °C	-40 °C	2	1	35 ns	GMR (Giant Magnetoresistive)	40 Mbps
NVE Corp/Isolation Products IL 3585VE	16-SOIC	6000 Vrms	3 V, 4.5 V	5.5 V	RS422, RS485	30 kV/µs	16-SOIC	0.295 in	7.5 mm	Unidirectional	Surface Mount	3	85 °C	-40 °C	2	1	35 ns	GMR (Giant Magnetoresistive)	40 Mbps
NVE Corp/Isolation Products IL 3585	16-SOIC	2500 Vrms	3 V, 4.5 V	5.5 V	RS422, RS485	30 kV/µs	16-SOIC	0.295 in	7.5 mm	Unidirectional	Surface Mount	3	85 °C	-40 °C	2	1	35 ns	GMR (Giant Magnetoresistive)	40 Mbps
NVE Corp/Isolation Products IL 3585E	16-SOIC	2500 Vrms	3 V, 4.5 V	5.5 V	RS422, RS485	30 kV/µs	16-SOIC	0.295 in	7.5 mm	Unidirectional	Surface Mount	3	85 °C	-40 °C	2	1	35 ns	GMR (Giant Magnetoresistive)	40 Mbps
