89HP0504PZBNRGI
ObsoleteRenesas Electronics Corporation
IC INTFACE SPECIALIZED 36VFQFPN
89HP0504PZBNRGI
ObsoleteRenesas Electronics Corporation
IC INTFACE SPECIALIZED 36VFQFPN
Description
General part information
89HP0504P Series
The IDT 89HP0504P 4-channel PCIe Gen2 Repeater offers the industry a blend of top analog performance, lower power, and the most system level features in signal repeaters optimized for demanding 2.5Gbps to 5Gbps applications in computing, storage, and communications.
Technical Specifications
Parameters and characteristics for this part
| Specification | 89HP0504PZBNRGI |
|---|---|
| Applications | Switch Interfacing |
| Interface | PCI Express |
| Mounting Type | Surface Mount |
| Package / Case | 36-VFQFN Exposed Pad |
| Package Length | 4 mm |
| Package Name | 36-VFQFPN |
| Package Width | 7.5 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
