Samtec-ERM8-020-09.0-S-DV-K-TR Connector Headers and PCB Receptacles Conn Micro High Speed Terminal Strip HDR 40 POS 0.8mm Solder ST SMD T/R

ERM8-020-09.0-S-DV-K-TR

Active
Samtec Inc.

CONN MICRO HIGH SPEED TERMINAL STRIP HDR 40 POS 0.8MM SOLDER ST SMD T/R

Find alt
Samtec-ERM8-020-09.0-S-DV-K-TR Connector Headers and PCB Receptacles Conn Micro High Speed Terminal Strip HDR 40 POS 0.8mm Solder ST SMD T/R

ERM8-020-09.0-S-DV-K-TR

Active
Samtec Inc.

CONN MICRO HIGH SPEED TERMINAL STRIP HDR 40 POS 0.8MM SOLDER ST SMD T/R

Find alt

Description

General part information

ERM8-020 Series

40 Position Connector Header, Center Strip Contacts Surface Mount Gold

Technical Specifications

Parameters and characteristics for this part

SpecificationERM8-020-09.0-S-DV-K-TR
Connector TypeHeader, Center Strip Contacts
Contact FinishGold
Contact Finish Thickness30 µin
FeaturesBoard Guide, Pick and Place
Height Above Board0.508 in
Mated Stacking Height Options19mm, 14mm, 16mm
Mounting TypeSurface Mount
Number of Positions40
Number of Rows2
Pitch0.031 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Sign in to see pricing

Create a free account to access distributor pricing data.

Sign up — freeLog in

CAD

3D models and CAD resources for this part
