Specification	0395272011

Color	Black
Contact Material	Copper Alloy
Contact Mating Finish	Tin
Current - UL	10 A
Features	Retention Latches (Non-Wire Side), Mating Flange
Housing Material	Nylon 6/6, Polyamide, PA66
Insulation Height	1.02 in
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Number of Positions	11
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Pitch	0.197 in
Plug Wire Entry Angle	270 °
Positions Per Level	11
Screw Size	M3
Termination Style	Screw - Rising Cage Clamp
Torque - Screw	0.34 Nm
Type	Female Sockets, Plug
Voltage - UL	300 V
Wire Gauge or Range - AWG (Max)	25.5 AWG
Wire Gauge or Range - AWG (Min)	12 AWG
Wire Strip Length	5 mm

039527 Series

Part	Features	Positions Per Level	Color	Termination Style	Type	Contact Mating Finish	Operating Temperature (Min)	Operating Temperature (Max)	Plug Wire Entry Angle	Number of Positions	Number of Levels	Mounting Type	Voltage - UL	Wire Gauge or Range - AWG (Min)	Wire Gauge or Range - AWG (Max)	Pitch	Current - UL	Housing Material	Material Flammability Rating	Torque - Screw	Insulation Height	Contact Material	Wire Strip Length	Screw Size
Molex 0395278010	Mating Flange Retention Latches (Wire Side)	10	Green	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	90 °	10	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Phosphor Bronze	5 mm
Molex 0395277014	Mating Flange Retention Latches (Non-Wire Side)	14	Green	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	270 °	14	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Copper Alloy	5 mm	M3
Molex 0395272021	Mating Flange Retention Latches (Non-Wire Side)	21	Black	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	270 °	21	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Copper Alloy	5 mm	M3
Molex 0395273004	Mating Flange Retention Latches (Wire Side)	4	Black	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	90 °	4	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Phosphor Bronze	5 mm
Molex 0395272015	Mating Flange Retention Latches (Non-Wire Side)	15	Black	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	270 °	15	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Copper Alloy	5 mm	M3
Molex 0395278016	Mating Flange Retention Latches (Wire Side)	16	Green	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	90 °	16	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Phosphor Bronze	5 mm
Molex 0395273013	Mating Flange Retention Latches (Wire Side)	13	Black	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	90 °	13	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Phosphor Bronze	5 mm
Molex 0395273024	Mating Flange Retention Latches (Wire Side)	24	Black	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	90 °	24 pos	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Phosphor Bronze	5 mm
Molex 0395273017	Mating Flange Retention Latches (Wire Side)	17	Black	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	90 °	17	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Phosphor Bronze	5 mm
Molex 0395272011	Mating Flange Retention Latches (Non-Wire Side)	11	Black	Screw - Rising Cage Clamp	Female Sockets Plug	Tin	-40 °C	105 °C	270 °	11	1	Free Hanging (In-Line)	300 V	12 AWG	25.5 AWG	0.197 in	10 A	Nylon 6/6 PA66 Polyamide	UL94 V-0	0.34 Nm	1.02 in	Copper Alloy	5 mm	M3
