CF898-060

Active

Igus

CABLE 4COND 22AWG VIO SHLD 1=1FT

Search across all available documentation for this part.

Active

Igus

CABLE 4COND 22AWG VIO SHLD 1=1FT

Technical Specifications

Parameters and characteristics for this part

Specification	CF898-060

Cable Type	Multi-Conductor
Conductor Insulation	Thermoplastic Elastomer (TPE)
Conductor Material	Copper, Bare
Features	Flame Retardant, Oil Resistant
Jacket (Insulation) Diameter [diameter]	0.276 in
Jacket (Insulation) Diameter [diameter]	7.01 mm
Jacket (Insulation) Material	Polyurethane (PU)
Jacket Color	Violet
Length	Enter Number of Feet in Order Quantity
Number of Conductors	4
Shield Coverage	60 %
Shield Material	Copper, Tinned
Shield Type	Braid
Voltage	50 V
Wire Gauge	22 AWG

Part	Cable Type	Wire Gauge	Jacket (Insulation) Material	Jacket Color	Conductor Insulation	Shield Coverage	Voltage	Features	Shield Type	Conductor Material	Shield Material	Number of Conductors	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length
Igus CF898-060	Multi-Conductor	22 AWG	Polyurethane (PU)	Violet	Thermoplastic Elastomer (TPE)	60 %	50 V	Flame Retardant Oil Resistant	Braid	Copper Bare	Copper Tinned	4	0.276 in	7.01 mm	Enter Number of Feet in Order Quantity
Igus CF898-021	Multi-Conductor	20 AWG	Polyurethane (PU)	Violet	Thermoplastic Elastomer (TPE)	60 %	50 V	Flame Retardant Oil Resistant	Braid	Copper Bare	Copper Tinned	2	0.335 "	8.51 mm	Enter Number of Feet in Order Quantity

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Conductor Multi-Conductor Cable Violet 22 AWG Braid Enter Number of Feet in Order Quantity
