Specification	HDT15-PR

Color	Black
Connector Layout	High Density, DE, E
Connector Style	High Density, D-Sub
Connector Type	Plug for Male Contacts
Dielectric Material	Glass Filled, Polybutylene Terephthalate (PBT)
Features	Grounding Indents
Finish	Tin Plated
Flange Feature	Shell (Unthreaded), Housing
Mounting Type	Free Hanging (In-Line)
Number of Positions	15
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-65 °C
Shell Material	Steel
Shell Size	1

HDT15 Series

Part	Dielectric Material	Color	Operating Temperature (Max)	Operating Temperature (Min)	Flange Feature	Connector Type	Features	Mounting Type	Number of Positions	Finish	Shell Material	Connector Style	Shell Size	Connector Layout	Contact Type	Current Rating	Contact Finish	Material Flammability Rating	Termination	Number of Rows	Contact Material	Voltage Rating	Contact Finish Thickness	Contact Finish Thickness (string set options)	Contact Finish Thickness
Adam Tech HDT15-PR	Glass Filled Polybutylene Terephthalate (PBT)	Black	125 °C	-65 °C	Housing Shell (Unthreaded)	Plug for Male Contacts	Grounding Indents	Free Hanging (In-Line)	15	Tin Plated	Steel	D-Sub High Density	1	DE E High Density
Adam Tech HDT15-SD	Glass Filled Polybutylene Terephthalate (PBT)	Black			Housing Shell (Unthreaded)	Female Sockets Receptacle		Free Hanging (In-Line)	15	Tin Plated	Steel	D-Sub High Density	1	DE E High Density	Signal	3 A	Gold	UL94 V-0	Solder Cup	3	Copper Alloy	250 V
Adam Tech HDT15-PD	Glass Filled Polybutylene Terephthalate (PBT)	Black			Housing Shell (Unthreaded)	Male Pins Plug	Grounding Indents	Free Hanging (In-Line)	15	Tin Plated	Steel	D-Sub High Density	1	DE E High Density		3 A	Gold	UL94 V-0	Solder Cup	3	Copper Alloy	250 V
Adam Tech HDT15-ST	Glass Filled Polybutylene Terephthalate (PBT)	Black			Housing Shell (Unthreaded)	Female Sockets Receptacle		Through Hole	15	Tin Plated	Steel	D-Sub High Density	1	DE E High Density		3 A	Gold	UL94 V-0	Solder	3	Copper Alloy	250 V	0	Flash	Flash
