NTPS-48-10

Active

RED LION CONTROLS

AC/DC DIN RAIL SUPPLY 48V 480W

Search across all available documentation for this part.

Active

RED LION CONTROLS

AC/DC DIN RAIL SUPPLY 48V 480W

Technical Specifications

Parameters and characteristics for this part

Specification	NTPS-48-10

AC Voltage - Input [Max]	240 VAC
AC Voltage - Input [Min]	100 VAC
Applications	ITE (Commercial)
Approval Agency	cULus, cURus, CE, cCSAus
Current - Output (Max) [Max]	10 A
Efficiency	93.9 %
Features	Adjustable Output, PFC, IP20, Load Sharing
Input Type	AC
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Power (Watts)	480 W
Size / Dimension [x]	5 in
Size / Dimension [x]	127 mm
Size / Dimension [y]	2.56 "
Size / Dimension [y]	65 mm
Size / Dimension [z]	4.88 "
Size / Dimension [z]	124 mm
Voltage - Isolation	3000 V
Voltage - Output 1	48 V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 1	Power (Watts)	Applications	Approval Agency	Input Type	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Number of Outputs	Efficiency	Voltage - Isolation	Features	Current - Output (Max) [Max]
RED LION CONTROLS NTPS-48-10	-25 °C	70 °C	48 V	480 W	ITE (Commercial)	cCSAus CE cULus cURus	AC	100 VAC	240 VAC	4.88 "	2.56 "	65 mm	5 in	127 mm	124 mm	1	93.9 %	3000 V	Adjustable Output IP20 Load Sharing PFC	10 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 1532.57

General part information

AC/DC DIN RAIL SUPPLY 48V 480W

Technical documentation and resources

No documents available
