RN232-4-02-3M3
ActiveTE Connectivity Raychem Cable Protection
CMC 3.3MH 4A 2LN TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
RN232-4-02-3M3
ActiveTE Connectivity Raychem Cable Protection
CMC 3.3MH 4A 2LN TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | RN232-4-02-3M3 |
|---|---|
| Approval Agency | ENEC, UR, VDE |
| Current Rating (Max) [Max] | 4 A |
| DC Resistance (DCR) (Max) | 54 mOhm |
| Filter Type | Power Line |
| Height (Max) [Max] | 1.362 in |
| Height (Max) [Max] | 34.6 mm |
| Inductance @ Frequency | 3.3 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4 Lead |
| Package / Case | Vertical |
| Size / Dimension [x] | 1.22 in |
| Size / Dimension [x] | 31 mm |
| Size / Dimension [y] | 18 mm |
| Size / Dimension [y] | 0.709 " |
| Voltage Rating - AC | 300 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 4.18 | |
| 10 | $ 3.50 | |||
| 25 | $ 3.19 | |||
| 50 | $ 2.74 | |||
| 100 | $ 2.51 | |||
| 300 | $ 2.43 | |||
| 600 | $ 2.36 | |||
| 1200 | $ 2.22 | |||
Description
General part information
RN232 Series
3.3 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 4A DCR 54mOhm (Typ)
