MAXREFDES108#
ActiveAnalog Devices Inc./Maxim Integrated
REF DESIGN POE MAX5969A MAX17505
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXREFDES108#
ActiveAnalog Devices Inc./Maxim Integrated
REF DESIGN POE MAX5969A MAX17505
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MAXREFDES108# |
|---|---|
| Board Type | Fully Populated |
| Current - Output | 1 A |
| Frequency - Switching | 500 kHz |
| Main Purpose | Special Purpose DC/DC, Power Over Ethernet |
| Outputs and Type | Non-Isolated |
| Outputs and Type | 1 |
| Power - Output | 12 W |
| Regulator Topology | Buck |
| Supplied Contents | Board(s) |
| Utilized IC / Part | MAX5969A, MAX17505 |
| Voltage - Input [Max] | 57 V |
| Voltage - Input [Min] | 36 V |
| Voltage - Output | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 33.87 | |
| 10 | $ 33.79 | |||
MAXREFDES108 Series
REF DESIGN POE MAX5969A MAX17505
| Part | Outputs and Type | Outputs and Type | Voltage - Input [Min] | Voltage - Input [Max] | Supplied Contents | Regulator Topology | Board Type | Voltage - Output | Frequency - Switching | Main Purpose | Power - Output | Utilized IC / Part | Current - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXREFDES108# | Non-Isolated | 1 | 36 V | 57 V | Board(s) | Buck | Fully Populated | 12 V | 500 kHz | Power Over Ethernet, Special Purpose DC/DC | 12 W | MAX17505, MAX5969A | 1 A |
Description
General part information
MAXREFDES108 Series
MAX5969A, MAX17505 - Special Purpose DC/DC, Power Over Ethernet 1, Non-Isolated Outputs Evaluation Board
