MAX11635EVSYS#

Active

Analog Devices Inc./Maxim Integrated

KIT EVAL SYSTEM

Search across all available documentation for this part.

Active

Analog Devices Inc./Maxim Integrated

KIT EVAL SYSTEM

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

MAX11635 - 12 Bit 300k Samples per Second Analog to Digital Converter (ADC) Evaluation Board

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	MAX11635EVSYS#	MAX11635 Series

Architecture	-	SAR
Configuration	-	S/H-ADC
Data Interface	QSPI™, Serial, SPI™, MICROWIRE™	SPI, QSPI™, Serial, SPI™, MICROWIRE™
Input Range	±VREF	±VREF
Input Type	-	Single Ended, Differential
Mounting Type	-	Surface Mount
Number of A/D Converters	1	1
Number of Bits	12 bits	12 bits
Number of Inputs	-	2 - 4
Operating Temperature	-	85 °C
Operating Temperature	-	-40 °C
Package / Case	-	0.154 in
Package / Case	-	16-SSOP
Package / Case	-	3.9 mm
Ratio - S/H:ADC	-	1:1
Reference Type	-	External, Internal
Sampling Rate (Per Second)	300 kHz	300 kHz
Supplied Contents	Board(s)	Board(s)
Supplier Device Package	-	16-QSOP
Utilized IC / Part	MAX11635	MAX11635
Voltage - Supply, Analog	-	2.7 V
Voltage - Supply, Analog	-	3.6 V
Voltage - Supply, Digital	-	3.6 V
Voltage - Supply, Digital	-	2.7 V

IC ADC 12BIT SAR 16QSOP

Part	Supplier Device Package	Configuration	Input Type	Operating Temperature [Max]	Operating Temperature [Min]	Reference Type	Mounting Type	Number of A/D Converters	Voltage - Supply, Digital [Max]	Voltage - Supply, Digital [Min]	Number of Bits	Sampling Rate (Per Second)	Voltage - Supply, Analog [Min]	Voltage - Supply, Analog [Max]	Architecture	Ratio - S/H:ADC	Package / Case	Package / Case	Package / Case	Data Interface	Number of Inputs	Utilized IC / Part	Input Range	Supplied Contents
Analog Devices Inc./Maxim Integrated MAX11635EEE+T	16-QSOP	S/H-ADC	Differential, Single Ended	85 °C	-40 °C	External, Internal	Surface Mount	1	3.6 V	2.7 V	12 bits	300 kHz	2.7 V	3.6 V	SAR	1:1	0.154 in	16-SSOP	3.9 mm	SPI	2, 4
Analog Devices Inc./Maxim Integrated MAX11635EEE+	16-QSOP	S/H-ADC	Differential, Single Ended	85 °C	-40 °C	External, Internal	Surface Mount	1	3.6 V	2.7 V	12 bits	300 kHz	2.7 V	3.6 V	SAR	1:1	0.154 in	16-SSOP	3.9 mm	SPI	2, 4
Analog Devices Inc./Maxim Integrated MAX11635EVSYS#								1			12 bits	300 kHz								MICROWIRE™, QSPI™, Serial, SPI™		MAX11635	±VREF	Board(s)
Analog Devices Inc./Maxim Integrated MAX11635EVKIT#								1			12 bits	300 kHz								MICROWIRE™, QSPI™, Serial, SPI™		MAX11635	±VREF	Board(s)
