121872A 0081000

Active

Belden Inc.

CABLE CAT6 8CON 23AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

CABLE CAT6 8CON 23AWG GRAY

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	121872A 0081000	121872A Series

Cable Type	Multi-Pair, Cat6	Multi-Pair, Cat6
Conductor Insulation	Polyolefin (PO)	Polyolefin (PO)
Conductor Material	Copper, Bare	Copper, Bare
Conductor Strand	Solid	Solid
Jacket (Insulation) Diameter [diameter]	18.42 mm	18.42 mm
Jacket (Insulation) Diameter [diameter]	0.725 in	0.725 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	1.27 mm	1.27 mm
Jacket (Insulation) Thickness	0.05 in	0.05 in
Jacket Color	Gray	Gray, Black
Length	1000 ft	1000 ft
Length	304.8 m	304.8 m
Length	-	609.6 m
Length	-	2000 ft
Number of Conductors	8	8
Operating Temperature [Max]	75 ░C	75 ░C
Operating Temperature [Min]	-40 °C	-40 °C
Usage	Industrial, Network	Industrial, Network
Voltage	300 V	300 V
Wire Gauge	23 AWG	23 AWG

CABLE CAT6 8CON 23AWG GRAY

Part	Conductor Strand	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Conductor Insulation	Voltage	Conductor Material	Jacket Color	Length	Length	Number of Conductors	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Usage	Length [x]	Length [x]
Belden Inc. 121872A 0081000	Solid	18.42 mm	0.725 in	23 AWG	Polyolefin (PO)	300 V	Copper, Bare	Gray	1000 ft	304.8 m	8	1.27 mm	0.05 in	Multi-Pair, Cat6	Poly-Vinyl Chloride (PVC)	-40 °C	75 ░C	Industrial, Network
Belden Inc. 121872A 0102000	Solid	18.42 mm	0.725 in	23 AWG	Polyolefin (PO)	300 V	Copper, Bare	Black			8	1.27 mm	0.05 in	Multi-Pair, Cat6	Poly-Vinyl Chloride (PVC)	-40 °C	75 ░C	Industrial, Network	609.6 m	2000 ft
Belden Inc. 121872A 0101000	Solid	18.42 mm	0.725 in	23 AWG	Polyolefin (PO)	300 V	Copper, Bare	Black	1000 ft	304.8 m	8	1.27 mm	0.05 in	Multi-Pair, Cat6	Poly-Vinyl Chloride (PVC)	-40 °C	75 ░C	Industrial, Network

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 5.36

General part information

8 (4 Pair Twisted) Conductor Multi-Pair, Cat6 Cable Gray 23 AWG 1000.0' (304.8m)
