837-22-007-30-001101

Active

Mill-Max Manufacturing Corp.

CONN SPRING PISTON 7POS SMD

Search across all available documentation for this part.

Active

Mill-Max Manufacturing Corp.

CONN SPRING PISTON 7POS SMD

Technical Specifications

Parameters and characteristics for this part

Part	Number of Contacts	Contact Finish Thickness	Contact Finish Thickness	Mounting Type	Material	Pitch [x]	Pitch [x]	Contact Finish	Connector Type	Number of Rows
Mill-Max Manufacturing Corp. 837-22-010-30-001101	10	10 Áin	0.25 Ám	Surface Mount	Copper Alloy	2.54 mm	0.1 in	Gold	Piston	1
Mill-Max Manufacturing Corp. 837-22-064-30-001101	64	10 Áin	0.25 Ám	Surface Mount	Copper Alloy	2.54 mm	0.1 in	Gold	Piston	1
Mill-Max Manufacturing Corp. 837-22-007-30-001101	7	10 Áin	0.25 Ám	Surface Mount	Copper Alloy	2.54 mm	0.1 in	Gold	Piston	1
Mill-Max Manufacturing Corp. 837-22-008-30-001101	8	10 Áin	0.25 Ám	Surface Mount	Copper Alloy	2.54 mm	0.1 in	Gold	Piston	1
Mill-Max Manufacturing Corp. 837-22-001-30-001101	1	10 Áin	0.25 Ám	Surface Mount	Copper Alloy	2.54 mm	0.1 in	Gold	Piston	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

7 Position Spring Piston Connector Surface Mount

Technical documentation and resources

No documents available
