SEAMP-20-02.0-L-06

Active

Samtec Inc.

CONN HD ARRAY M 120POS PRESS-FIT

Search across all available documentation for this part.

Active

Samtec Inc.

CONN HD ARRAY M 120POS PRESS-FIT

Technical Specifications

Parameters and characteristics for this part

Part	Connector Type	Mated Stacking Heights	Number of Positions	Contact Finish	Height Above Board	Height Above Board	Number of Rows	Pitch [x]	Pitch [x]	Mounting Type	Contact Finish Thickness	Contact Finish Thickness	Features
Samtec Inc. SEAMP-20-02.0-L-06	High Density Array Male	7 mm 8 mm 8.5 mm	120	Gold	0.181 in	4.6 mm	6	0.05 in	1.27 mm	Through Hole	10 Áin	0.25 Ám
Samtec Inc. SEAMP-20-02.0-L-08	High Density Array Male	7 mm 8 mm 8.5 mm	160	Gold	0.181 in	4.6 mm	8	0.05 in	1.27 mm	Through Hole	10 Áin	0.25 Ám
Samtec Inc. SEAMP-20-02.0-S-04	High Density Array Male	7 mm 8 mm 8.5 mm	80	Gold	0.181 in	4.6 mm		0.05 in	1.27 mm	Through Hole	30 Áin	0.76 Ám
Samtec Inc. SEAMP-20-02.0-L-10	High Density Array Male	7 mm 8 mm 8.5 mm		Gold	0.181 in	4.6 mm	10	0.05 in	1.27 mm	Through Hole	10 Áin	0.25 Ám
Samtec Inc. SEAMP-20-02.0-L-10-TR	High Density Array Male	7 mm 8 mm 8.5 mm		Gold	0.181 in	4.6 mm	10	0.05 in	1.27 mm	Through Hole	10 Áin	0.25 Ám	Board Guide
Samtec Inc. SEAMP-20-02.0-L-08-GP	High Density Array Male	7 mm 8 mm 8.5 mm	160	Gold	0.181 in	4.6 mm	8	0.05 in	1.27 mm	Through Hole	10 Áin	0.25 Ám	Board Guide

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	96	$ 11.82

General part information

120 Position Connector High Density Array, Male Through Hole Gold
