3SB22046BG06

Active

Siemens

PILOT LIGHT,BLU,FV W/O BULB,RING

Search across all available documentation for this part.

Active

Siemens

PILOT LIGHT,BLU,FV W/O BULB,RING

Technical Specifications

Parameters and characteristics for this part

Part	Type	Termination Style	Lens Size [diameter]	Ingress Protection	Ratings	Panel Cutout Dimensions	Panel Cutout Dimensions	Panel Cutout Shape	Voltage [Min]	Voltage [Max]	Lens Transparency	Lamp Color
Siemens 3SB22046BC06	LED	Tab Terminal	16 mm	IP65	AC/DC	0.63 in	16 mm	Round	5 V	60 V
Siemens 3SB22046BH06	LED	Tab Terminal	16 mm	IP65	AC/DC	0.63 in	16 mm	Round	5 V	60 V	Clear
Siemens 3SB22046BG06	LED	Tab Terminal	16 mm	IP65	AC/DC	0.63 in	16 mm	Round	5 V	60 V
Siemens 3SB22046BD06	LED	Screw Terminal	22 mm	IP65	AC/DC	0.63 in	16 mm	Round	5 V	60 V		Yellow
Siemens 3SB22046BE06	LED	Tab Terminal	16 mm	IP65	AC/DC	0.63 in	16 mm	Round	5 V	60 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator 5V ~ 60V Tab Terminal
