MAXM17574EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT MAXM17574 3A REG
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXM17574EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT MAXM17574 3A REG
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXM17574EVKIT# | MAXM17574 Series |
|---|---|---|
| Applications | - | ITE (Commercial) |
| Board Type | Fully Populated | Fully Populated |
| Current - Output | 3 A | 3 A |
| Current - Output (Max) | - | 3 A |
| Features | - | OTP, UVLO, OCP |
| Frequency - Switching | 650 kHz | 650 kHz |
| Main Purpose | DC/DC, Step Down | DC/DC, Step Down |
| Mounting Type | - | Surface Mount |
| Number of Outputs | - | 1 |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Outputs and Type | Non-Isolated | Non-Isolated |
| Outputs and Type | 1 | 1 |
| Package / Case | - | 33-PowerBLGA Module |
| Size / Dimension | - | 15 mm |
| Size / Dimension | - | 0.11 in |
| Size / Dimension | - | 0.59 in |
| Size / Dimension | - | 9 mm |
| Size / Dimension | - | 2.8 mm |
| Size / Dimension | - | 0.35 " |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 33-LGA (15x9) |
| Type | - | Non-Isolated PoL Module |
| Utilized IC / Part | MAXM17574 | MAXM17574 |
| Voltage - Input (Max) | - | 60 V |
| Voltage - Input (Min) | - | 4.5 V |
| Voltage - Input [Max] | 60 V | 60 V |
| Voltage - Input [Min] | 10 V | 10 V |
| Voltage - Output | 5 V | 5 V |
| Voltage - Output 1 | - | 0.9 V |
| Voltage - Output 1 | - | 15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 39.28 | |
MAXM17574 Series
DC DC CONVERTER 0.9-15V
| Part | Voltage - Input (Min) [Min] | Package / Case | Type | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Number of Outputs | Current - Output (Max) [Max] | Features | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] | Mounting Type | Applications | Voltage - Input (Max) [Max] | Supplier Device Package | Operating Temperature [Max] | Operating Temperature [Min] | Frequency - Switching | Outputs and Type | Outputs and Type | Board Type | Voltage - Input [Min] | Voltage - Input [Max] | Supplied Contents | Main Purpose | Current - Output | Utilized IC / Part | Voltage - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXM17574ALC# | 4.5 V | 33-PowerBLGA Module | Non-Isolated PoL Module | 15 mm | 0.11 in | 0.59 in | 9 mm | 2.8 mm | 0.35 " | 1 | 3 A | OCP, OTP, UVLO | 0.9 V | 15 V | Surface Mount | ITE (Commercial) | 60 V | 33-LGA (15x9) | 125 °C | -40 °C | |||||||||||
Analog Devices Inc./Maxim Integrated MAXM17574EVKIT# | 650 kHz | Non-Isolated | 1 | Fully Populated | 10 V | 60 V | Board(s) | DC/DC, Step Down | 3 A | MAXM17574 | 5 V | ||||||||||||||||||||
Analog Devices Inc./Maxim Integrated MAXM17574ALC#T | 4.5 V | 33-PowerBLGA Module | Non-Isolated PoL Module | 15 mm | 0.11 in | 0.59 in | 9 mm | 2.8 mm | 0.35 " | 1 | 3 A | OCP, OTP, UVLO | 0.9 V | 15 V | Surface Mount | ITE (Commercial) | 60 V | 33-LGA (15x9) | 125 °C | -40 °C |
Description
General part information
MAXM17574 Series
MAXM17574 Himalaya DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
