MPLCV0654L330
ActiveKEMET
POWER INDUCTOR (SMD), AEC-Q200, 33 ΜH, 2.6 A, SHIELDED, 4 A, MPLCV SERIES
Deep-Dive with AI
Search across all available documentation for this part.
MPLCV0654L330
ActiveKEMET
POWER INDUCTOR (SMD), AEC-Q200, 33 ΜH, 2.6 A, SHIELDED, 4 A, MPLCV SERIES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MPLCV0654L330 |
|---|---|
| Current - Saturation (Isat) | 4 A |
| Current Rating (Amps) | 2.6 A |
| DC Resistance (DCR) | 140 mOhm |
| Height - Seated (Max) [Max] [z] | 5.4 mm |
| Height - Seated (Max) [Max] [z] | 0.213 in |
| Inductance | 33 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal Composite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension [x] | 0.311 " |
| Size / Dimension [x] | 7.9 mm |
| Size / Dimension [y] | 6.7 mm |
| Size / Dimension [y] | 0.264 in |
| Tolerance | 20 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.88 | |
| 10 | $ 2.45 | |||
| 25 | $ 2.25 | |||
| 50 | $ 2.02 | |||
| 100 | $ 1.68 | |||
| 250 | $ 1.63 | |||
| 500 | $ 1.54 | |||
| Digi-Reel® | 1 | $ 2.88 | ||
| 10 | $ 2.45 | |||
| 25 | $ 2.25 | |||
| 50 | $ 2.02 | |||
| 100 | $ 1.68 | |||
| 250 | $ 1.63 | |||
| 500 | $ 1.54 | |||
| Tape & Reel (TR) | 1000 | $ 1.44 | ||
| 3000 | $ 1.39 | |||
| 5000 | $ 1.34 | |||
| Newark | Each (Supplied on Full Reel) | 2000 | $ 1.46 | |
| 4000 | $ 1.32 | |||
| 6000 | $ 1.27 | |||
| 10000 | $ 1.22 | |||
Description
General part information
MPLCV0654 Series
33 µH Shielded Inductor 2.6 A 140mOhm Nonstandard
