AA30T051212A

Obsolete

Delta Electronics

AC/DC CONVERTER 5V +/-12V 30W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AA30T051212A

Obsolete

Delta Electronics

AC/DC CONVERTER 5V +/-12V 30W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

AA30T Series

Enclosed AC DC Converters 3 Output 5V 3A, 600mA, 600mA 85 ~ 264 VAC Input

Documents

Technical documentation and resources

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AA30T051212A	AA30T Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	cUL, UL, CE	CE, cUL, UL
Current - Output (Max)	600 mA	600 mA
Current - Output (Max)	600 mA	600 mA
Current - Output (Max)	3 A	1 - 250 mA
Current - Output 1	-	1 - 4.5 A
Current - Output 2	-	1 - 250 A
Current - Output 3	-	3 - 250 mA
Efficiency	76 %	71 - 76 %
Features	Universal Input	Universal Input, DC Input Capable
Line Regulation	±0.2%	±0.2%
Load Regulation	2.5 %, 4 %	2.5 - 4 %
Minimum Load Required	-	False
Mounting Type	Through Hole	Chassis Mount, Through Hole
Number of Outputs	3	3
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-25 °C	-25 °C
Package / Case	7-DIP Module	7-DIP Module
Power (Watts)	30 W	30 W
Size / Dimension [x]	3.5 in	3.5 - 4.41 "
Size / Dimension [x]	89.9 mm	89.9 - 112 mm
Size / Dimension [y]	63.5 mm	63.5 - 63.8 mm
Size / Dimension [y]	2.5 in	2.5 - 2.51 "
Size / Dimension [z]	0.85 "	0.85 - 1.01 in
Size / Dimension [z]	21.7 mm	21.7 - 25.6 mm
Standard Number	60950-1	60950-1
Type	Enclosed	Enclosed
Voltage - Isolation	-	3000 V
Voltage - Output 1	5 V	3.3 - 12 V
Voltage - Output 2	-	-12 - 5 V
Voltage - Output 3	-	5 - 12 V
Weight	176.9 g	176.9 g
Weight	0.39 lb	0.39 lb

AA30T Series

AC/DC POWER SUPPLY TRIPLE-OUT 5V/3.3V/12V 4.5A/1A/0.25A 30W 7-PIN CARTON

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Operating Temperature [Max]	Operating Temperature [Min]	Current - Output 3	Current - Output 2	Approval Agency	Current - Output 1	Voltage - Output 1	Voltage - Output 2	Number of Outputs	Voltage - Isolation	Voltage - Output 3	Efficiency	Applications	Mounting Type	Type	Power (Watts)	Features	Weight	Weight	Package / Case	Load Regulation	Current - Output (Max)	Line Regulation	Standard Number	Current - Output (Max)	Current - Output (Max)
Delta Electronics AA30T050312C	63.8 mm	112 mm	4.41 "	25.6 mm	1.01 in	2.51 "	70 °C	-25 °C	250 mA	1 A	CE	4.5 A	5 V	3.3 V	3	3000 V	12 V	71 %	ITE (Commercial)	Chassis Mount	Enclosed	30 W	DC Input Capable, Universal Input
Delta Electronics AA30T030512A	63.5 mm	89.9 mm	3.5 in	21.7 mm	0.85 "	2.5 in	70 °C	-25 °C			CE, cUL, UL		3.3 V		3			71 %	ITE (Commercial)	Through Hole	Enclosed	30 W	Universal Input	176.9 g	0.39 lb	7-DIP Module	2.5 %, 4 %	1.5 A, 4 A, 250 mA	±0.2%	60950-1
Delta Electronics AA30T050312A	63.5 mm	89.9 mm	3.5 in	21.7 mm	0.85 "	2.5 in	70 °C	-25 °C			CE, cUL, UL		5 V		3			71 %	ITE (Commercial)	Through Hole	Enclosed	30 W	Universal Input	176.9 g	0.39 lb	7-DIP Module	2.5 %, 4 %	1 A, 4.5 A, 250 mA	±0.2%	60950-1
Delta Electronics AA30T121205C	63.8 mm	112 mm	4.41 "	25.6 mm	1.01 in	2.51 "	70 °C	-25 °C	3 A	250 mA	CE	1 A	12 V	-12 V	3	3000 V	5 V	76 %	ITE (Commercial)	Chassis Mount	Enclosed	30 W	DC Input Capable, Universal Input
Delta Electronics AA30T030512C	63.8 mm	112 mm	4.41 "	25.6 mm	1.01 in	2.51 "	70 °C	-25 °C	250 mA	1.5 A	CE	4 A	3.3 V	5 V	3	3000 V	12 V	71 %	ITE (Commercial)	Chassis Mount	Enclosed	30 W	DC Input Capable, Universal Input
Delta Electronics AA30T051212A	63.5 mm	89.9 mm	3.5 in	21.7 mm	0.85 "	2.5 in	70 °C	-25 °C			CE, cUL, UL		5 V		3			76 %	ITE (Commercial)	Through Hole	Enclosed	30 W	Universal Input	176.9 g	0.39 lb	7-DIP Module	2.5 %, 4 %	3 A	±0.2%	60950-1	600 mA	600 mA
