Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 56.86 | |
General part information
AMW006 - Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN) 2.4GHz Evaluation Board
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | AMW007-E04 | AMW007 Series |
|---|---|---|
| - | - | |
| Contents | Board(s) | Board(s) |
| Current - Receiving | - | 65 mA |
| Current - Transmitting | - | 100 mA |
| Current - Transmitting | - | 200 mA |
| Data Rate | - | 72.2 Mbps |
| For Use With/Related Products | - | AMW006 |
| Frequency | 2.4 GHz | 2.4 GHz |
| Frequency | - | 2.484 GHz |
| Frequency | - | 2.412 GHz |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 38-SMD Module, Module |
| Power - Output | - | 20 dBm |
| Protocol | - | 802.11b/g/n |
| RF Family/Standard | - | WiFi |
| Sensitivity | - | -93 dBm |
| Serial Interfaces | - | PWM, SPI, UART |
| Supplied Contents | - | Board(s) |
| Type | Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN) | Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN) |
| Utilized IC / Part | AMW006 | AMW006 |
| Voltage - Supply | - | 3.6 V |
| Voltage - Supply | - | 3 V |
| Voltage - Supply | - | 3.3 V |
RF TXRX MODULE WIFI SMD
| Part | Serial Interfaces | RF Family/Standard | Data Rate | Protocol | Voltage - Supply [Max] | Voltage - Supply [Min] | Mounting Type | Current - Receiving | Sensitivity | Power - Output | Current - Transmitting [Min] | Current - Transmitting [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Frequency [Max] | Frequency [Min] | Type | Frequency | Contents | Utilized IC / Part | For Use With/Related Products | Supplied Contents | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Silicon Labs AMW007-1.3.0R | PWM, SPI, UART | WiFi | 72.2 Mbps | 802.11b/g/n | 3.6 V | 3 V | Surface Mount | 65 mA | -93 dBm | 20 dBm | 100 mA | 200 mA | 85 °C | -40 °C | 38-SMD Module | 2.484 GHz | 2.412 GHz | |||||||
Silicon Labs AMW007-E04 | Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN) | 2.4 GHz | Board(s) | AMW006 | ||||||||||||||||||||
Silicon Labs AMW007-E03 | Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN) | 2.4 GHz | Board(s) | AMW006 | AMW006 | Board(s) | ||||||||||||||||||
Silicon Labs AMW007-1.4.0 | ||||||||||||||||||||||||
Silicon Labs AMW007-1.1.2R | ||||||||||||||||||||||||
Silicon Labs AMW007-1.2.0R | SPI, UART | WiFi | 802.11b/g/n | Surface Mount | 65 mA | -93 dBm | 20 dBm | 100 mA | 200 mA | 85 °C | -40 °C | Module | 2.4 GHz | 3.3 V | ||||||||||
Silicon Labs AMW007-1.4.0R |
