Q-1X0690008012i
ActiveAmphenol Custom Cable
CBL ASSY RPSMA-NTYPE PLG-JCK 12"
Deep-Dive with AI
Search across all available documentation for this part.
Q-1X0690008012i
ActiveAmphenol Custom Cable
CBL ASSY RPSMA-NTYPE PLG-JCK 12"
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | Q-1X0690008012i |
|---|---|
| 1st Connector | RP-SMA Plug |
| 1st Connector Mounting Feature | Bulkhead - Front Side Nut |
| 1st Connector Mounting Type | Panel Mount |
| 1st Contact Gender | Female |
| 2nd Connector | N-Type Jack |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Contact Gender | Female |
| Cable Type | RG-58 |
| Color | Black |
| Features | Shielded |
| Frequency - Max [Max] | 11 GHz |
| Length | 12 " |
| Length | 304.8 mm |
| Overall Impedance | 50 Ohms |
| Style | RP-SMA to N-Type |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 146.89 | |
| 25 | $ 144.78 | |||
| 50 | $ 142.66 | |||
| 100 | $ 140.55 | |||
| 250 | $ 138.43 | |||
Description
General part information
Q-1X0690 Series
Cable Assembly Coaxial RP-SMA to N-Type RG-58 12.00" (304.80mm)
Documents
Technical documentation and resources
No documents available
