FDD1-17251CBHW32
ActiveQualtek
FAN AXIAL 172X51MM 12VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FDD1-17251CBHW32
ActiveQualtek
FAN AXIAL 172X51MM 12VDC WIRE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FDD1-17251CBHW32 |
|---|---|
| Air Flow | 325 CFM |
| Air Flow | 9.1 m³/min |
| Approval Agency | cURus, CE, TUV |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Lifetime @ Temp. | 50000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Aluminum |
| Noise | 64 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 44.8 W |
| RPM | 4000 RPM |
| Size / Dimension | Rectangular/Rounded |
| Size / Dimension [x] | 172 mm |
| Size / Dimension [z] | 151 mm |
| Static Pressure | 282.5 Pa |
| Static Pressure | 1.134 in H2O |
| Termination | 2 Wire Leads |
| Voltage - Rated | 12 VDC |
| Weight | 1 kg |
| Weight | 2.3 lbs |
| Width [y] | 51 mm |
FDD1-17251 Series
| Part | Current Rating (Amps) | Static Pressure | Static Pressure | Approval Agency | Noise | RPM | Weight | Weight | Air Flow | Air Flow | Termination | Bearing Type | Width [y] | Size / Dimension [z] | Size / Dimension | Size / Dimension [x] | Material - Frame | Power (Watts) | Material - Blade | Fan Type | Ingress Protection | Lifetime @ Temp. | Voltage - Rated | Operating Temperature [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Air Flow | Features | Voltage - Rated [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Qualtek | 2.75 A | 230.4 Pa | 0.925 in H2O | CE cURus TUV | 60 dB(A) | 3600 RPM | 2.5 lbs | 1.1 kg | 8.12 m³/min | 290 CFM | 2 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 33 W | Plastic | Tubeaxial | IP56M - Dust Protected Water Resistant | 100000 Hrs | 12 VDC | -20 °C | 70 °C | -20 C | 70 °C | |||
Qualtek | 282.5 Pa | 1.134 in H2O | CE cURus TUV | 64 dB(A) | 4000 RPM | 2.3 lbs | 1 kg | 9.1 m³/min | 2 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 44.8 W | Plastic | Tubeaxial | 50000 Hrs | 12 VDC | -20 °C | 70 °C | -20 C | 70 °C | 325 CFM | |||||
Qualtek | 0.89 A | 183.3 Pa | 0.736 in H2O | CE cURus TUV | 56 dB | 3200 RPM | 2.5 lbs | 1.1 kg | 7.14 mł/min | 255 CFM | 4 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 21.4 W | Plastic | Tubeaxial | IP56M - Dust Protected Water Resistant | 100000 Hrs | 24 VDC | -20 °C | 70 °C | -20 C | 70 °C | PWM Control Speed Sensor (Tach) | ||
Qualtek | 282.5 Pa | 1.134 in H2O | CE cURus TUV | 64 dB(A) | 4000 RPM | 2.5 lbs | 1.1 kg | 9.1 m³/min | 325 CFM | 3 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 44.8 W | Plastic | Tubeaxial | IP54 - Dust Protected Water Resistant | 50000 Hrs | 12 VDC | -20 °C | 70 °C | -20 C | 70 °C | PWM Control | |||
Qualtek | 1.88 A | 183.3 Pa | 0.736 in H2O | CE cURus TUV | 56 dB | 3200 RPM | 2.5 lbs | 1.1 kg | 7.14 mł/min | 255 CFM | 3 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 22.6 W | Plastic | Tubeaxial | IP56M - Dust Protected Water Resistant | 100000 Hrs | 12 VDC | -20 °C | 70 °C | -20 C | 70 °C | Speed Sensor (Tach) | ||
Qualtek | 0.89 A | 183.3 Pa | 0.736 in H2O | CE cURus TUV | 56 dB | 3200 RPM | 2.5 lbs | 1.1 kg | 7.14 mł/min | 255 CFM | 3 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 21.4 W | Plastic | Tubeaxial | IP56M - Dust Protected Water Resistant | 100000 Hrs | 24 VDC | -20 °C | 70 °C | -20 C | 70 °C | Speed Sensor (Tach) | ||
Qualtek | 0.79 A | 282.5 Pa | 1.134 in H2O | CE cURus TUV | 64 dB(A) | 4000 RPM | 2.3 lbs | 1 kg | 9.1 m³/min | 325 CFM | 2 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 37.9 W | Plastic | Tubeaxial | 50000 Hrs | -20 °C | 70 °C | -20 C | 70 °C | 48 VDC | ||||
Qualtek | 1.21 A | 230.4 Pa | 0.925 in H2O | CE cURus TUV | 60 dB(A) | 3600 RPM | 2.5 lbs | 1.1 kg | 8.12 m³/min | 290 CFM | 3 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 29 W | Plastic | Tubeaxial | IP54 - Dust Protected Water Resistant | 50000 Hrs | 24 VDC | -20 °C | 70 °C | -20 C | 70 °C | Speed Sensor (Tach) | ||
Qualtek | 1.88 A | 183.3 Pa | 0.736 in H2O | CE cURus TUV | 56 dB | 3200 RPM | 2.5 lbs | 1.1 kg | 7.14 mł/min | 255 CFM | 3 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 22.6 W | Plastic | Tubeaxial | IP54 - Dust Protected Water Resistant | 100000 Hrs | 12 VDC | -20 °C | 70 °C | -20 C | 70 °C | Locked Rotor Sensor | ||
Qualtek | 1.21 A | 230.4 Pa | 0.925 in H2O | CE cURus TUV | 60 dB(A) | 3600 RPM | 2.5 lbs | 1.1 kg | 8.12 m³/min | 290 CFM | 2 Wire Leads | Ball | 51 mm | 151 mm | Rectangular/Rounded | 172 mm | Aluminum | 29 W | Plastic | Tubeaxial | IP54 - Dust Protected Water Resistant | 50000 Hrs | 24 VDC | -20 °C | 70 °C | -20 C | 70 °C |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 92.68 | |
| 12 | $ 83.30 | |||
| 36 | $ 82.13 | |||
| 60 | $ 76.85 | |||
| 108 | $ 75.09 | |||
Description
General part information
FDD1-17251 Series
Fan Tubeaxial 12VDC Rectangular/Rounded - 172mm L x 151mm H Ball 325.0 CFM (9.10mł/min) 2 Wire Leads
