SDM1100LP-7

Active

Diodes Inc

RECTIFIER DIODE, SCHOTTKY, 1 ELEMENT, 1A, 100V V(RRM), SILICON, U-DFN2020-2, 2 PIN

Search across all available documentation for this part.

Active

Diodes Inc

RECTIFIER DIODE, SCHOTTKY, 1 ELEMENT, 1A, 100V V(RRM), SILICON, U-DFN2020-2, 2 PIN

Technical Specifications

Parameters and characteristics for this part

Specification	SDM1100LP-7

Capacitance @ Vr, F	40 pF
Current - Average Rectified (Io)	1 A
Current - Reverse Leakage @ Vr	350 µA
Grade	Automotive
Mounting Type	Surface Mount
Operating Temperature - Junction [Max]	175 ░C
Operating Temperature - Junction [Min]	-55 C
Package / Case	2-UDFN
Qualification	AEC-Q101
Speed	200 mA, 500 ns
Supplier Device Package	U-DFN2020-2
Technology	Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	100 V
Voltage - Forward (Vf) (Max) @ If	770 mV

1A 100 VOLT SCHOTTKY BARRIER RECTIFIER

Part	Current - Reverse Leakage @ Vr	Current - Average Rectified (Io)	Qualification	Voltage - Forward (Vf) (Max) @ If	Voltage - DC Reverse (Vr) (Max) [Max]	Grade	Package / Case	Capacitance @ Vr, F	Supplier Device Package	Technology	Mounting Type	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Speed
Diodes Inc SDM1100LP-7	350 µA	1 A	AEC-Q101	770 mV	100 V	Automotive	2-UDFN	40 pF	U-DFN2020-2	Schottky	Surface Mount	175 ░C	-55 C	200 mA 500 ns
Diodes Inc SDM1100S1F-7	5 µA	1 A		820 mV	100 V		SOD-123F		SOD-123F	Schottky	Surface Mount	150 °C	-55 °C	200 mA 500 ns

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

The device is a single rectifier packaged in SOD123F (Type B). It offers low VFand excellent high temperature stability.
