CFB700-48S28P

Active

Cincon Electronics Co. LTD

DC DC CONVERTER 28V 700W

Search across all available documentation for this part.

Active

Cincon Electronics Co. LTD

DC DC CONVERTER 28V 700W

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CFB700-48S28P	CFB700 Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	CE, cURus	CE, cURus
Control Features	Active High, Enable	Active Low, Enable, Active High
Current - Output (Max) [Max]	25 A	25 A
Efficiency	91 %	91 %
Features	Remote On/Off	Remote On/Off
Mounting Type	Through Hole	Through Hole
Number of Outputs	1	1
Operating Temperature [Max]	100 °C	100 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	Full Brick	Full Brick
Power (Watts)	700 W	700 W
Size / Dimension [x]	4.6 "	4.6 "
Size / Dimension [x]	116.8 mm	116.8 mm
Size / Dimension [y]	2.4 "	2.4 "
Size / Dimension [y]	61 mm	61 mm
Size / Dimension [z]	0.5 in	0.5 in
Size / Dimension [z]	12.7 mm	12.7 mm
Standard Number	60950-1	60950-1
Supplier Device Package	Full Brick	Full Brick
Type	Isolated Module	Isolated Module
Voltage - Input (Max) [Max]	75 V	75 V
Voltage - Input (Min) [Min]	36 V	36 V
Voltage - Isolation	1.5 kV	1.5 kV
Voltage - Output 1	28 V	28 V

DC DC CONVERTER 28V 700W

Part	Package / Case	Features	Type	Voltage - Isolation	Current - Output (Max) [Max]	Standard Number	Voltage - Input (Max) [Max]	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Voltage - Input (Min) [Min]	Applications	Efficiency	Number of Outputs	Control Features	Voltage - Output 1	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Mounting Type	Approval Agency
Cincon Electronics Co. LTD CFB700-48S28	Full Brick	Remote On/Off	Isolated Module	1.5 kV	25 A	60950-1	75 V	Full Brick	100 °C	-40 °C	700 W	36 V	ITE (Commercial)	91 %	1	Active Low, Enable	28 V	0.5 in	4.6 "	116.8 mm	12.7 mm	2.4 "	61 mm	Through Hole	CE, cURus
Cincon Electronics Co. LTD CFB700-48S28P	Full Brick	Remote On/Off	Isolated Module	1.5 kV	25 A	60950-1	75 V	Full Brick	100 °C	-40 °C	700 W	36 V	ITE (Commercial)	91 %	1	Active High, Enable	28 V	0.5 in	4.6 "	116.8 mm	12.7 mm	2.4 "	61 mm	Through Hole	CE, cURus

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 250.00

General part information

Isolated Module DC DC Converter 1 Output 28V 25A 36V - 75V Input
