8A-06AFFM-SR7A01
ActiveAmphenol LTW
CBL 6POS RCPT RA TO WIRE 3.28'
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
8A-06AFFM-SR7A01
ActiveAmphenol LTW
CBL 6POS RCPT RA TO WIRE 3.28'
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 8A-06AFFM-SR7A01 |
|---|---|
| 1st Connector Gender | Female Sockets |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Connector Number of Positions | 6 |
| 1st Connector Number of Positions Loaded | All |
| 1st Connector Orientation [custom] | Keyed |
| 1st Connector Shell Size - Insert | M8 |
| 1st Connector Type | Receptacle, Right Angle |
| 2nd Connector Type | Wire Leads |
| Assembly Configuration | Standard |
| Cable Material | Polyvinyl Chloride (PVC) |
| Cable Type | Round |
| Color | Black |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Length [x] | 1 m |
| Length [x] | 3.28 ft |
| Shielding | Shielded |
| Usage | Industrial Environments |
8A-06AFFM Series
| Part | 1st Connector Mounting Type | 1st Connector Number of Positions Loaded | Usage | 1st Connector Type | 1st Connector Number of Positions | Shielding | 1st Connector Orientation [custom] | 1st Connector Gender | Assembly Configuration | Ingress Protection | Cable Type | Color | Length [x] | Length [x] | Cable Material | 1st Connector Shell Size - Insert | 2nd Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol LTW | Free Hanging (In-Line) | All | Industrial Environments | Receptacle | 6 | Shielded | Keyed | Female Sockets | Standard | IP67 - Dust Tight Waterproof | Round | Black | 1.64 ft | 500 mm | Polyvinyl Chloride (PVC) | M8 | Wire Leads |
Amphenol LTW | Free Hanging (In-Line) | All | Industrial Environments | Receptacle Right Angle | 6 | Shielded | Keyed | Female Sockets | Standard | IP67 - Dust Tight Waterproof | Round | Black | 3.28 ft | 1 m | Polyvinyl Chloride (PVC) | M8 | Wire Leads |
Amphenol LTW | Free Hanging (In-Line) | All | Industrial Environments | Receptacle Right Angle | 6 | Shielded | Keyed | Female Sockets | Standard | IP67 - Dust Tight Waterproof | Round | Black | 6.56 ft | 2 m | Polyvinyl Chloride (PVC) | M8 | Wire Leads |
Amphenol LTW | Free Hanging (In-Line) | All | Industrial Environments | Receptacle Right Angle | 6 | Shielded | Keyed | Female Sockets | Standard | IP67 - Dust Tight Waterproof | Round | Black | 9.84 ft | 3 m | Polyvinyl Chloride (PVC) | M8 | Wire Leads |
Amphenol LTW | Free Hanging (In-Line) | All | Industrial Environments | Receptacle Right Angle | 6 | Shielded | Keyed | Female Sockets | Standard | IP67 - Dust Tight Waterproof | Round | Black | Polyvinyl Chloride (PVC) | M8 | Wire Leads | ||
Amphenol LTW | Free Hanging (In-Line) | All | Industrial Environments | Receptacle | 6 | Shielded | Keyed | Female Sockets | Standard | IP67 - Dust Tight Waterproof | Round | Black | 9.84 ft | 3 m | Polyvinyl Chloride (PVC) | M8 | Wire Leads |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 14.41 | |
| 10 | $ 11.08 | |||
| 25 | $ 10.02 | |||
| 50 | $ 9.30 | |||
| 100 | $ 8.65 | |||
| 250 | $ 7.88 | |||
| 500 | $ 7.36 | |||
| 1000 | $ 6.89 | |||
Description
General part information
8A-06AFFM Series
Circular Cable Assembly Shielded 3.28' (1.00m)
