ET60S-D03-0-00-000-L-V1-S

Active

Samtec Inc.

CONN RCPT 3POS PCB

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

ET60S-D03-0-00-000-L-V1-S

Active

Samtec Inc.

CONN RCPT 3POS PCB

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ET60S-D03-0-00-000-L-V1-S

Color	Black
Connector Style	EXTreme Ten60Power
Connector Type	Receptacle, Female Blade Sockets
Contact Finish	Gold
Contact Finish Thickness	10 Áin
Contact Finish Thickness	0.25 Ám
Contact Layout, Typical	3 Power
Features	Mating Guide, Board Guide
Mounting Type	Through Hole
Number of Positions Loaded	All
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Termination	Solder
Voltage Rating	250 VDC

ET60S-D03 Series

Part	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows	Connector Style	Mounting Type	Number of Positions Loaded	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Contact Layout, Typical [custom]	Contact Layout, Typical [custom]	Color	Connector Type	Number of Positions	Features	Voltage Rating	Pitch [x]	Pitch [x]	Termination	Contact Layout, Typical
Samtec Inc. ET60S-D03-3-08-D02-S-V1-S	-40 °C	105 ░C	3	EXTreme Ten60Power	Through Hole	All	Gold	0.76 Ám	30 Áin	24	5	Black	Blade Sockets Female Sockets Receptacle	29	Board Guide Mating Guide	250 VDC	2.54 mm	0.1 in	Solder
Samtec Inc. ET60S-D03-3-08-D02-L-R1-S	-40 °C	105 ░C	3	EXTreme Ten60Power	Through Hole Right Angle	All	Gold	0.25 Ám	10 Áin	24	5	Black	Blade Sockets Female Sockets Receptacle	29	Board Guide Mating Guide	250 VDC	2.54 mm	0.1 in	Solder
Samtec Inc. ET60S-D03-3-08-D03-L-VP-S	-40 °C	105 ░C	3	EXTreme Ten60Power	Through Hole	All	Gold	0.25 Ám	10 Áin	24	6	Black	Blade Sockets Female Sockets Receptacle	30	Board Guide Mating Guide	250 VDC	2.54 mm	0.1 in	Press-Fit
Samtec Inc. ET60S-D03-0-00-D03-S-R1-S	-40 °C	105 ░C		EXTreme Ten60Power	Through Hole Right Angle	All	Gold	0.76 Ám	30 Áin			Black	Receptacle Female Blade Sockets	6	Board Guide Mating Guide	250 VDC			Solder	6 Power
Samtec Inc. ET60S-D03-3-08-D04-L-V1-S	-40 °C	105 ░C	3	EXTreme Ten60Power	Through Hole	All	Gold	0.25 Ám	10 Áin	24	7	Black	Blade Sockets Female Sockets Receptacle	31	Board Guide Mating Guide	250 VDC	2.54 mm	0.1 in	Solder
Samtec Inc. ET60S-D03-0-00-000-L-V1-S	-40 °C	105 ░C		EXTreme Ten60Power	Through Hole	All	Gold	0.25 Ám	10 Áin			Black	Receptacle Female Blade Sockets		Board Guide Mating Guide	250 VDC			Solder	3 Power
Samtec Inc. ET60S-D03-3-08-D04-S-R1-S	-40 °C	105 ░C	3	EXTreme Ten60Power	Through Hole Right Angle	All	Gold	0.76 Ám	30 Áin	24	7	Black	Blade Sockets Female Sockets Receptacle	31	Board Guide Mating Guide	250 VDC	2.54 mm	0.1 in	Solder
Samtec Inc. ET60S-D03-0-00-000-L-R1-S	-40 °C	105 ░C		EXTreme Ten60Power	Through Hole Right Angle	All	Gold	0.25 Ám	10 Áin			Black	Receptacle Female Blade Sockets		Board Guide Mating Guide	250 VDC			Solder	3 Power
Samtec Inc. ET60S-D03-0-00-D03-S-VP-S	-40 °C	105 ░C		EXTreme Ten60Power	Through Hole	All	Gold	0.76 Ám	30 Áin			Black	Receptacle Female Blade Sockets	6	Board Guide Mating Guide	250 VDC			Press-Fit	6 Power
Samtec Inc. ET60S-D03-3-08-D03-S-R1-S	-40 °C	105 ░C	3	EXTreme Ten60Power	Through Hole Right Angle	All	Gold	0.76 Ám	30 Áin	24	6	Black	Blade Sockets Female Sockets Receptacle	30	Board Guide Mating Guide	250 VDC	2.54 mm	0.1 in	Solder

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	63	$ 4.67

Description

General part information

ET60S-D03 Series

3 Connector Receptacle, Female Blade Sockets Through Hole Black EXTreme Ten60Power
