Specification	DK-Z7-VIDEO-G-J

Contents	Board, Accessories - Power Supply Not Included -, Cable
For Use With/Related Products	XC7Z020
Interconnect System	Pmod, FMC
P/N Breakdown	J = Japan version does not ship with a power supply
Platform	Zynq-7000 AP SoC ZC702 Video and Imaging Japan
Suggested Programming Environment	ISE, Vivado
Type	FPGA + MCU/MPU SoC
Utilized IC / Part	XC7Z020

XC7Z020 Series

Part	P/N Breakdown	Interconnect System	For Use With/Related Products	Suggested Programming Environment	Type	Utilized IC / Part	Contents	Platform	Number of I/O	RAM Size	Package / Case	Peripherals	Package Width	Package Name	Package Length	Operating Temperature (Max)	Operating Temperature (Min)	Connectivity	Core Processor	Primary Attributes	Logic Elements	Architecture	Speed
AMD / Xilinx DK-Z7-VIDEO-CES-G-J	J = Japan version does not ship with a power supply	FMC Pmod	XC7Z020	ISE Vivado	FPGA + MCU/MPU SoC	XC7Z020	Accessories - Power Supply Not Included - Board Cable	Zynq-7000 AP SoC ZC702 Video and Imaging CES Japan
AMD / Xilinx DK-Z7-VIDEO-G-J	J = Japan version does not ship with a power supply	FMC Pmod	XC7Z020	ISE Vivado	FPGA + MCU/MPU SoC	XC7Z020	Accessories - Power Supply Not Included - Board Cable	Zynq-7000 AP SoC ZC702 Video and Imaging Japan
AMD / Xilinx EK-Z7-ZC702-G-J	J = Japan version does not ship with a power supply	FMC Pmod	XC7Z020	ISE Vivado	FPGA + MCU/MPU SoC	XC7Z020	Accessories - Power Supply Not Included - Board Cable	Zynq-7000 AP SoC ZC702 Japan
AMD / Xilinx XC7Z020-1CLG484CES									130	256 KB	484-LFBGA CSPBGA	DMA	19 mm	484-CSPBGA	19 mm	85 °C	0 °C	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG	Dual ARM® Cortex®-A9 MPCore™ with CoreSight™	Artix™-7 FPGA	85 K Logic Elements	FPGA MCU	667 MHz
AMD / Xilinx XC7Z020-1CLG400CES									130	256 KB	400-LFBGA CSPBGA	DMA	17 mm	400-CSPBGA	17 mm	85 °C	0 °C	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG	Dual ARM® Cortex®-A9 MPCore™ with CoreSight™	Artix™-7 FPGA	85 K Logic Elements	FPGA MCU	667 MHz
AMD / Xilinx XC7Z020-2CLG484I										256 KB	484-LFBGA CSPBGA	DMA	19 mm	484-CSPBGA	19 mm	100 °C	-40 °C	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG	Dual ARM® Cortex®-A9 MPCore™ with CoreSight™	Artix™-7 FPGA	85 K Logic Elements	FPGA MCU	766 MHz
AMD / Xilinx XC7Z020-3CLG400E									130	256 KB	400-LFBGA CSPBGA	DMA	17 mm	400-CSPBGA	17 mm	100 °C	0 °C	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG	Dual ARM® Cortex®-A9 MPCore™ with CoreSight™	Artix™-7 FPGA	85 K Logic Elements	FPGA MCU	866 MHz
AMD / Xilinx XC7Z020-2CLG484CES									130	256 KB	484-LFBGA CSPBGA	DMA	19 mm	484-CSPBGA	19 mm	85 °C	0 °C	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG	Dual ARM® Cortex®-A9 MPCore™ with CoreSight™	Artix™-7 FPGA	85 K Logic Elements	FPGA MCU	766 MHz
AMD / Xilinx XC7Z020-3CLG484E									130	256 KB	484-LFBGA CSPBGA	DMA	19 mm	484-CSPBGA	19 mm	100 °C	0 °C	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG	Dual ARM® Cortex®-A9 MPCore™ with CoreSight™	Artix™-7 FPGA	85 K Logic Elements	FPGA MCU	866 MHz
AMD / Xilinx XC7Z020-L1CLG400I									130	256 KB	400-LFBGA CSPBGA	DMA	17 mm	400-CSPBGA	17 mm	100 °C	-40 °C	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG	Dual ARM® Cortex®-A9 MPCore™ with CoreSight™	Artix™-7 FPGA	85 K Logic Elements	FPGA MCU	667 MHz

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

No documents available
