G-BASIC Series

Part	Accuracy	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)	Output Type	Voltage - Supply	Mounting Type	Applications	Output Voltage (Max)	Termination Style	Operating Pressure	Port Feature	Port Gender	Port Diameter	Port Style	Pressure Type	Features
McGill Microwave Systems 10 INCH-G-BASIC	0.5 % RH	4-SIP Module	85 °C	-25 °C	Wheatstone Bridge	6 V	Through Hole	Board Mount	30 mV	PC Pin	0.36 PSI	Dual Tube	Male	0.08 in	Barbless	Vented Gauge	Temperature Compensated
McGill Microwave Systems 5 INCH-G-BASIC	0.5 % RH	4-SIP Module	85 °C	-25 °C	Wheatstone Bridge	6 V	Through Hole	Board Mount	22.5 mV	PC Pin	0.18 PSI	Tube	Male	0.08 in	Barbless	Vented Gauge	Temperature Compensated
McGill Microwave Systems 30 INCH-G-BASIC	0.5 % RH	4-SIP Module	85 °C	-25 °C	Wheatstone Bridge	6 V	Through Hole	Board Mount	30 mV	PC Pin	1.08 PSI	Dual Tube	Male	0.08 in	Barbless	Vented Gauge	Temperature Compensated
McGill Microwave Systems 20 INCH-G-BASIC	0.5 % RH	4-SIP Module	85 °C	-25 °C	Wheatstone Bridge	6 V	Through Hole	Board Mount	30 mV	PC Pin	0.72 PSI	Tube	Male	0.08 in	Barbless	Vented Gauge	Temperature Compensated

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
