2-2232875-1
ActiveTE Connectivity AMP Connectors
CONN HOUSING PL 2 POS 6MM CRIMP ST CABLE MOUNT BOX/CARTON
2-2232875-1
ActiveTE Connectivity AMP Connectors
CONN HOUSING PL 2 POS 6MM CRIMP ST CABLE MOUNT BOX/CARTON
Description
General part information
GRACE INERTIA 6.0 Series
2 Position, Plug, Housing, Crimp, Wire-to-Board, Tin (Sn), UL 94V-0, 6 mm [.236 in] Centerline, 1 Row, 300 VAC, Wire & Cable, GRACE INERTIA 6.0
Technical Specifications
Parameters and characteristics for this part
| Specification | 2-2232875-1 |
|---|---|
| Color | Natural |
| Connector Type | Plug |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Latch Lock |
| Insulation Material | Nylon, Polyamide (PA) |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.236 in |
