5767055-4
ActiveTE Connectivity AMP Connectors
CONN PLUG 152POS EDGE MNT GOLD
5767055-4
ActiveTE Connectivity AMP Connectors
CONN PLUG 152POS EDGE MNT GOLD
Description
General part information
5767055 Series
PCB Mount Header, Straddle Mount, Board-to-Board, 152 Position, .64 mm [.025 in] Centerline, Gold (Au), Surface Mount, Signal, Black, Box / Tube
Technical Specifications
Parameters and characteristics for this part
| Specification | 5767055-4 |
|---|---|
| Connector Type | Plug, Outer Shroud Contacts |
| Contact Finish | Gold |
| Contact Finish Thickness | 30 µin |
| Features | Ground Bus (Plane), Board Guide |
| Height Above Board | 0.251 in |
| Mounting Type | Straddle Mount, Board Edge |
| Number of Positions | 152 |
| Number of Rows | 2 |
| Pitch | 0.025 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
