General part information
General Purpose Relays Relay Plug-In DPDT 10A 12VDC
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | RU-3.30505 | RU Series |
|---|---|---|
| Applications | ITE (Commercial) | ITE (Commercial) |
| Current - Output (Max) | 100 mA | 100 mA |
| Current - Output (Max) | 100 mA | 100 mA |
| Efficiency | 76 % | 72 - 76 % |
| Features | SCP | SCP |
| Mounting Type | Through Hole | Through Hole |
| Number of Outputs | 2 | 2 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 7-SIP Module, 6 Leads | 7-SIP Module, 6 Leads |
| Size / Dimension [x] | 0.77 in | 0.77 in |
| Size / Dimension [x] | 19.7 mm | 19.7 mm |
| Size / Dimension [y] | 0.24 " | 0.24 " |
| Size / Dimension [y] | 6 mm | 6 mm |
| Size / Dimension [z] | 10.2 mm | 10.2 mm |
| Size / Dimension [z] | 0.4 " | 0.4 " |
| Type | Isolated Module | Isolated Module |
| Voltage - Input (Max) [Max] | 3.6 V | 3.6 - 5.5 V |
| Voltage - Input (Min) [Min] | 3 V | 3 - 4.5 V |
| Voltage - Isolation | 1000 V | 1000 - 2000 V |
| Voltage - Output 1 | 5 V | 5 V |
| Voltage - Output 2 | 5 V | 5 V |
General Purpose Relays Relay Plug-In DPDT 10A 12VDC
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 2 | Number of Outputs | Package / Case | Voltage - Isolation | Voltage - Input (Max) [Max] | Current - Output (Max) | Current - Output (Max) | Type | Voltage - Output 1 | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Features | Applications | Efficiency | Voltage - Input (Min) [Min] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
RECOM Power RU-050505/P | 85 °C | -40 °C | 5 V | 2 | 7-SIP Module, 6 Leads | 1000 V | 5.5 V | 100 mA | 100 mA | Isolated Module | 5 V | 10.2 mm | 0.77 in | 19.7 mm | 0.24 " | 0.4 " | 6 mm | SCP | ITE (Commercial) | 72 % | 4.5 V | Through Hole |
RECOM Power RU-3.30505 | 85 °C | -40 °C | 5 V | 2 | 7-SIP Module, 6 Leads | 1000 V | 3.6 V | 100 mA | 100 mA | Isolated Module | 5 V | 10.2 mm | 0.77 in | 19.7 mm | 0.24 " | 0.4 " | 6 mm | SCP | ITE (Commercial) | 76 % | 3 V | Through Hole |
RECOM Power RU-3.30505/HP | 85 °C | -40 °C | 5 V | 2 | 7-SIP Module, 6 Leads | 2000 V | 3.6 V | 100 mA | 100 mA | Isolated Module | 5 V | 10.2 mm | 0.77 in | 19.7 mm | 0.24 " | 0.4 " | 6 mm | SCP | ITE (Commercial) | 76 % | 3 V | Through Hole |
