Specification	WAS350M12BM3

Channel Count	2
Configuration	N-Channel
Configuration - Features	Half Bridge
Current - Continuous Drain (Id) (Tc)	417 A
Drain to Source Voltage (Vdss)	1200 V
Gate Charge (Max)	844 nC
Input Capacitance (Ciss) (Max)	25700 pF, 25700 pF
Mounting Type	Chassis Mount
Operating Temperature (Max)	150 °C
Operating Temperature (Min)	-40 °C
Package / Case	Module
Rds On (Max)	5.2 mOhm
Technology	Silicon Carbide (SiC)
Vgs(th) (Max)	3.6 V

WAS350 Series

Part	Technology	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Vgs(th) (Max)	Mounting Type	Input Capacitance (Ciss) (Max)	Current - Continuous Drain (Id) (Tc)	Drain to Source Voltage (Vdss)	Rds On (Max)	Gate Charge (Max)	Channel Count	Configuration - Features	Configuration
Wolfspeed, Inc. WAS350M12BM3	Silicon Carbide (SiC)	-40 °C	150 °C	Module	3.6 V	Chassis Mount	25700 pF 25700 pF	417 A	1200 V	5.2 mOhm	844 nC	2	Half Bridge	N-Channel
