CQS24150-8

Obsolete

Cosel USA, Inc.

DC DC CONVERTER 15V

Search across all available documentation for this part.

Obsolete

Cosel USA, Inc.

DC DC CONVERTER 15V

Technical Specifications

Parameters and characteristics for this part

Part	Type	Number of Outputs	Current - Output (Max) [Max]	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Package / Case	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Input (Max) [Max]	Voltage - Isolation	Mounting Type	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Output 1	Features
Cosel USA, Inc. CQS24150-8-N	Isolated Module	1	8 A	ITE (Commercial)	85 °C	-40 °C	92 %	8-DIP Module	8.5 mm	2.28 in	1.45 in	0.33 in	36.8 mm	57.9 mm	33 V	1.5 kV	Through Hole	20 V	120 W	15 V
Cosel USA, Inc. CQS24150-8	Isolated Module	1	8 A	ITE (Commercial)	85 °C	-40 °C	92 %	8-DIP Module	8.5 mm	2.28 in	1.45 in	0.33 in	36.8 mm	57.9 mm	33 V	1.5 kV	Through Hole	20 V		15 V	OCP OTP OVP Remote On/Off
Cosel USA, Inc. CQS24150-8-R	Isolated Module	1	8 A	ITE (Commercial)	85 °C	-40 °C	92 %	8-DIP Module	8.5 mm	2.28 in	1.45 in	0.33 in	36.8 mm	57.9 mm	33 V	1.5 kV	Through Hole	20 V	120 W	15 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 1 Output 15V 8A 20V - 33V Input
