DELTA12 Series

Part	Number of Bands	Termination Type	RF Family/Standard	Frequency (Band)	Frequency (Center)	Gain	Mounting Type	VSWR	Frequency Group Maximum (VHF)	Frequency Group	Height (Max)	Applications	Antenna Type	Power - Max	Frequency Group Maximum (UHF)	Frequency Group Minimum (UHF)	Termination	Frequency (Center/Band)	Frequency Range (Max)	Frequency Range (Min)
Siretta DELTA12/X/SMAM/S/S/17	2	SMA Male	General ISM	173 MHz	151 MHz	3 dBi	Connector Mount	2	300 MHz	VHF	5.118 in	ISM	Straight Whip	50 VA
Siretta DELTA12A/X/BNCM/S/S/17	2		General ISM	458 MHz	433 MHz	3 dBi	Connector Mount	2		UHF	5.118 in	ISM	Straight Whip	50 VA	1 GHz	300 MHz	BNC Male
Siretta DELTA12/X/BNCM/S/S/17	2		General ISM	173 MHz	151 MHz	3 dBi	Connector Mount	2	300 MHz	VHF	5.118 in	ISM	Straight Whip	50 VA			BNC Male
Siretta DELTA12B/X/BNCM/S/S/17	1		General ISM			3 dBi	Connector Mount	2		UHF	5.118 in 6.496 in	ISM	Straight Whip	50 VA	1 GHz	300 MHz	BNC Male	868 MHz 869 MHz	870 MHz	863 MHz
Siretta DELTA12A/X/SMAM/S/S/17	2	SMA Male	General ISM	458 MHz	433 MHz	3 dBi	Connector Mount	2		UHF	5.118 in	ISM	Straight Whip	50 VA	1 GHz	300 MHz
Siretta DELTA12B/X/SMAM/S/S/17 HIGH GAIN	1	SMA Male	General ISM	173 MHz	151 MHz	3 dBi	Connector Mount	2	300 MHz	UHF VHF	5.118 in 5.906 in	ISM	Straight Whip	50 VA	1 GHz	300 MHz		868 MHz	870 MHz	863 MHz
Siretta DELTA12C/X/SMAM/S/S/17	1	SMA Male	General ISM			3 dBi	Connector Mount	2		UHF	5.118 in 5.906 in	ISM	Straight Whip	50 VA	1 GHz	300 MHz		915 MHz
Siretta DELTA12C/X/BNCM/S/S/17	1		General ISM			3 dBi	Connector Mount	2		UHF	5.118 in 5.906 in	ISM	Straight Whip	50 VA	1 GHz	300 MHz	BNC Male	915 MHz

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
